Fein BOP 6 - Circlip Pliers

BOP 6 (A); BOP 10 (A); BOP 10-2 (A); BOP 13-2 (A)
7. Fitting
C-SC_CSSM
Version 1.0
2017-10-12
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 58 of 65
Fitting the gearbox housing [applies to: BOP 13-2 (A)]
1. Fit the circlip (1).
2. Insert the draw keys (2).
3. Press draw keys outwards.
Tools:
- Slotted screwdriver
(small)
- Circlip pliers
1
2
