BOP 6 (A); BOP 10 (A); BOP 10-2 (A); BOP 13-2 (A)
6. Removal
C-SC_CSSM
Version 1.0
2017-10-12
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 26 of 65
Removing the handle half shell
1. Unscrew the three screws (1).
2. Unscrew the countersunk screw (2).
3. Remove the switch pushbutton (3).
4. Remove the handle half shell (4).
Tools:
- PH1/PH2 cross-head
screwdriver
1
2
3
4
