BOP 6 (A); BOP 10 (A); BOP 10-2 (A); BOP 13-2 (A)
6. Removal
C-SC_CSSM
Version 1.0
2017-10-12
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 27 of 65
Removing the cable with plug
1. Unscrew the screw (1).
2. Remove the cable clamping piece (2).
3. Remove the speed setting switch (3).
4. Undo the two screws (4) and remove the cable with plug.
Tools:
- PH1/PH2 cross-head
screwdriver
1
2
4
3
