BOP 6 (A); BOP 10 (A); BOP 10-2 (A); BOP 13-2 (A)
7. Fitting
C-SC_CSSM
Version 1.0
2017-10-12
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 44 of 65
Fitting the gearbox housing [applies to: BOP 6 (A)]
1. Place the clutch ring (1) in the correct position.
2. Fit the six rollers (2).
Tools:
- Forceps
1
2
