BOP 6 (A); BOP 10 (A); BOP 10-2 (A); BOP 13-2 (A)
7. Fitting
C-SC_CSSM
Version 1.0
2017-10-12
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 49 of 65
Fitting the gearbox housing [applies to: BOP 10 (A)]
1. Place the clutch ring (1) in the correct position.
2. Fit the six rollers (2).
Tools:
- Forceps
1
2
