BOP 6 (A); BOP 10 (A); BOP 10-2 (A); BOP 13-2 (A)
7. Fitting
C-SC_CSSM
Version 1.0
2017-10-12
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 60 of 65
Fitting the gearbox housing [applies to: BOP 13-2 (A)]
1. Fit the sleeve (1) in the correct position.
2. Fit the circlip (2).
Tools:
- Assembly aid
1
2
