5.1. Assembly – Drill jig / Guide
Move up the gear rod with the gear teeth of the gear box until the screw holes match together
Tighten the screws on the guide
Put in the pressure bar and adjust the feed rate
Tools:
- allen key 5 mm
- allen key 3 mm
