5.4. Assembly - Feed unit
Complete feed motor with spacer, ball bearing and worm wheel
The worm wheel is secured to the feed motor shaft with a set screw. The shaft
has a milled groove on one side with which the set screw must come into
contact.
Tool:
- Socket head wrench, size 3
