5.4. Assembly - Feed unit
Assemble feed motor and feed gearbox –
Warning, the spacer is not fixed. It must be in the recess and can easily slip out
of place during assembly. (See arrow)
Screw motor down to gearbox with four screws
Tool:
- Socket head wrench, size 3
