Fixed plate has USB port, connect to Camera to control shooting/recording, or focusing on
some Cameras.
UART1 / UART2 port can use for connecting Auto Focus
Camera Control USB port can use USB 2.0 to Type C / USB 2.0 to Mini / USB 3.0 to
Micro 3.0/ Panasonic Lumix Shutter Cable use 3.5mm jack to connect.
UART2
UART1
Connecting Panasonic
Lumix Shutter Cable
4.3 USB Ports
