FeiYu Tech SCORP 2 - Gimbal Balancing; 4.1 Balancing the tilt axis

- 5 -
2
1
4
3
1
It is recommended to push the camera against the tilt axis. Unlock ① to move the
camera left or right according to camera's width to adjust, then lock ① .
1
1
4. Gimbal Balancing
Please balance the gimbal before shooting. Make sure the
camera and lens are ready for shooting, and the gimbal
is powered o󽗈 or in sleep mode before balancing. It is
recommended to hold up the camera 󽗉rst, then move the
slide arm, cross arm and vertical arm.
Tutorial Videos
4.1 Balancing the tilt axis
4.1.1 Balancing the vertical tilt
a. Unlock the tilt lock ① , and loosen the slide arm lock ② .
b. Rotate the tilt axis so that the camera lens is pointing upward. Check the direction
