Part
Quantity
#140 011.0 Set screw D-916 - M3 x 6-N -
5
#140 012.0 Bolt D-7991- M3 x 6 --- 6N - CSK
5
#140 013.0 Bolt D-7991- M3 x 8 --- 8N - CSK
15
#140 016.0 Hexagon socket head cap screw DIN 912 - M3 x 12
5
#140 017.0 Hexagon socket head cap screw DIN 912 - M3 x 16
14
#140 018.0 Hexagon socket head cap screw DIN 912 M4 x 12
12
#140 019.0 Hexagon socket head cap screw DIN 912 M4 x 16
2
#140 020.0 Hexagon socket head cap screw DIN 912 M4 x 20
7
#140 021.0 Hexagon socket head cap screw DIN 912 M4 x 25
4
#140 022.0 Hexagon socket head cap screw DIN 912 M4 x 40
2
#140 023.0 Hexagon socket head cap screw DIN 912 M5 x 16
5
#140 024.0 WasherD-125A M3
6
#140 025.0 WasherD-125A M4
10
#140 026.0 WasherD-125A M5
5
#140 028.0 Corrosserie ring - M4 - large washer
2
#140 029.0 Prevailing torque type hexagon nut DIN-985 - M3
6
#140 030.0 Prevailing torque type hexagon nut DIN-985 - M4
6
#140 031.0 Hexagon Thin Nut D-439B - M4
8
#140 032.0 Powersupply screw UNC 6/32 x 1/4 Pozi steel
6
#140 037.0 Set screw D-916 - M4 x 30
2
#140 039.0 Spring Extruder & bed
4
#140 040.0 Thin square nut DIN 562 - Steel - M4
9
#110 021.0 t_slot nut - 8 ST M3
3
#140 070.0 Parker 2.2 x 8 - plaatschroef
6
