FELIXprinters FELIX One - Chapter 3: X-Axis

FELIXprinters Assembly Manual for the FELIX One
Page 11
29
(1x) Belt
27 28
30 31
(1x) T-Nut M4
(2x) Bearing
(1x) Small Washer M4
(1x) X-Axis Belt Mount
(1x) Bolt M4 x 40
(1x) T-Nut M4
Tools:
3
!! Washer !!
Tools:
3
Tools:
2
Tools:
2
(1x) X-Axis Belt Mount As-
sembly
Tools:
Chapter 3: X-Axis
60 Minutes
141,5
2 32,51,5
+
-
12
1
2
3
!! Make sure the short side of the T-nut is
facing the corner of the frame !!
