FELIXprinters FELIX One - Chapter 4: Y-Axis

FELIXprinters Assembly Manual for the FELIX One
Page 15
Tools:Tools:
52
(2x) Bolt M3 x 12
(1x) Y-Stage Bracket
50 51
53 54
(2x) Small Screw 2,2 x 8
(2x) Thin Nut M4
(1x) Opto sensor Y
(4x) Bolt M3 x 16
(4x) Locknut M3
(4x) Small Washer M3
(1x) Y-Stage Bracket Pt.1
(1x) Y-Stage Bracket Pt.2
(1x) Hiwin Linear Guide MGN12
(4x) Bolt M3 x 16
(4x) Small Washer M3
(1x) Y-Stage Assembly
!! (1x) Thin Nut M4 !!
!! (1x) Thin Nut M4 !!
+
!! Don’t let the Carriage run of the Rail !!
5,5
2,5
!! Endswitch Vane !!
Tools:
2,5
(1x) Tension Bracket
(1x) Bolt M4 x 25
(1x) Square Nut M4
Tools:
3
Tools:
2,5
!! Tighten in a Crosswise
Pattern !!
Tools:
Chapter 4: Y-Axis
30 Minutes
5,5
2,5
+
3
-
4
1
3
2
1
2
