FELIXprinters FELIX One - Chapter 2: Z-Axis

FELIXprinters Assembly Manual for the FELIX One
Page 8
Tools:
12
(4x) CSK Bolt M3 x 8
(1x) Motor
(1x) Z-Axis Motor Bracket
13 14
(1x) Cable Stepper Z
i
(1x) Motor Assembly
(2x) T-Nut M4
(2x) Bolt M4 x 20
(2x) Small Washer M4
Example - Insert T-Nut:
Insert the nut into the slot
Tools:Example - Insert T-Nut:
Insert the key into the
threaded hole and rotate
the nut into position.
2
2
Tools:
2
Tools:
3
Tools:
Chapter 2: Z-Axis
45 Minutes
41,5 2 3
1
2 3
