Page 16
58
(1x) Build Platform
(1x) Short Wire Sleeve
56 5755
(1x) Belt Tools:
-
!! Use the Screwdriver to Push the
Belt completely into the Socket !!
Tools:
!! Use the Screwdriver to Push the
Belt completely into the Socket !!
-
3
Tools:
2 cm
2
1
3
4
Tensioning the Belt:
Move the Y-Axis completely to one end. Tighten the belt using the
size 3 hexagon key until the belt can barely touch the rail of the
Y-Axis
59 60
M3 x 25
To Next Page
