FELIXprinters Assembly Manual for the FELIX One
Page 47
Prod. Nr.
Desciption
105 047.0
Set plastic parts
122 012.0
X_stage_F3_0_belt_mount_v1 - black
1
105 064.0
Y stage bracket prt1 with inserts Felix Tec4 Black
1
105 065.0
Y stage bracket prt2 with inserts Felix Tec4 Black
1
122 015.0
Y_stage_F3_0_tensioning_bracket_v1 - black
2
122 016.0
z_axis_F3_0_lift_part_v1 - black
1
122 017.0
z_axis_F3_0_motor_bracket_v1 - black
1
