30
CAUTION:
Retighten the fastening screws of the rotor arms
after the first 10 operating hours with 130 Nm.
12.2 Tires
CAUTION:
• Always ensure that the machine is safely
parked and secured so that it will not roll
away.
• Repair work on tyres and wheels must only
be carried out by professionals and with
correct tools.
• Observe the recommended tyre pressure.
Check tyre pressures regularly.
contact wheels 18x8.50-8 1.5 bar / 22 psi
tandem wheels 18x8.50-8 1.5 bar / 22 psi
transport wheels 11.5/80-15.3 2.5 bar / 36 psi
12.3 Maintenance of the PTO shaft
Comply with operating instructions provided by
manufacturer of drive shaft.
Before any use always check drive shafts for correct
installation, function and for complete equipment with
all protective devices.
12.4 Hydraulic system
CAUTION:
• The hydraulic system is under high pres-
sure.
• Inspect hydraulic hoses regularly and re-
place damaged and deteriorated hoses with
new ones.
• Before performing any work on the hydrau-
lic system, lower the machine, release the
pressure from the hydraulic system and
stop the engine.
• Escaping fluid (hydraulic oil) under high
pressure can penetrate the skin and cause
serious injury. If any fluid penetrates into
skin, consult a doctor immediately as oth-
erwise serious infections may result.
• When connecting hydraulic cylinders en-
sure the hydraulic hoses are connected cor-
rectly.
The time of usage of flexible tubing including possible
storage not exceed six
years. Within this period stor-
age should not exceed two years.
Connection diagram for hydraulic system (fig. 16).
A = standard equipment
B = Individual lifting device with 3 way valve
(see chapter 13.3)
C = Individual lifting device for rotors
(see chapter 13.2)
12.5 Lubrication scheme (see page 24)
For long-time parking in open air, clean piston rod and
subsequently preserve with grease or oil.
Take care for adequate disposal of oil and grease.
13. SPECIAL EQUIPMENT
13.1 Wide-angle transmission shaft.
(purchase no. 716 791)
13.2 Individual lifting device for rotors (fig. 16 C)
• purchase no. 716 774
• 2 hydraulic connections necessary
• Assembly according to assembly instruction.
13.3 Individual lifting device with 3 way valve
(fig. 16 B)
• purchase no. 716 806
• 1 hydraulic connection necessary
• Assembly according to assembly instruction.
13.4 Quantity devider for lifting device
• purchase no. 716 817
13.5 Spare wheel 18x8.50-8
• purchase no. 716 829
• Assembly according to assembly instruction.
