Fellowes ESI Evolve - Table of Contents

Evolve Table of contents
Basic components
Basic components ................................................................. 4
Configurations
F  Fixed / FS  Fixed Slider
EVOLVE1-F (SINGLE) .............................................. 6
EVOLVE1-FS (SINGLE) ............................................. 6
EVOLVE2-F (DUAL) .................................................. 6
EVOLVE2-FS (DUAL) ................................................ 6
M  Motion / MS - Motion Slider
EVOLVE1-M (SINGLE) ...............................................7
EVOLVE1-MS (SINGLE) .............................................7
EVOLVE2-M (DUAL) ..................................................7
EVOLVE2-MS (DUAL) ................................................7
FF - Fixed Fixed / FFS - Fixed Fixed Slider
EVOLVE1-FF (SINGLE) ............................................. 8
EVOLVE1-FFS (SINGLE) ........................................... 8
EVOLVE2-FF (DUAL) ................................................ 8
EVOLVE2-FFS (DUAL) ............................................. 8
EVOLVE3-FF (TRIPLE) ............................................. 8
EVOLVE3-FFS (TRIPLE) ........................................... 8
FM - Fixed Motion / FMS - Fixed Motion Slider
EVOLVE1-FM (SINGLE) ............................................ 9
EVOLVE1-FMS (SINGLE) ......................................... 9
EVOLVE2-FM (DUAL) ............................................... 9
EVOLVE2-FMS (DUAL) ............................................ 9
EVOLVE3-FM (TRIPLE) ............................................ 9
EVOLVE3-FMS (TRIPLE) ......................................... 9
Assembly steps
1. Pole mount .......................................................................10
2. Arm stems ........................................................................13
3. Attach arms ......................................................................14
4. Display mounts ...............................................................16
5. Attach display ..................................................................18
6. Adjust tension .................................................................19
7. Lock features .................................................................. 20
8. Cable management ......................................................22
Other
Allen key storage ................................................................. 23
Notes
QUAD DISPLAYS: Repeat the DUAL ASSEMBLY (EVOLVE2)
on the 28" pole.
For quad and six display configurations,
a 28" pole is required.
EVOLVE4M
EVOLVE4MS
EVOLVE4FF
EVOLVE4FFS
EVOLVE4FM
EVOLVE4FMS
SIX DISPLAYS: Repeat the TRIPLE ASSEMBLY (EVOLVE3) on
the 28” pole.
EVOLVE6FF
EVOLVE6FFS
EVOLVE6FM
EVOLVE6FMS

