PRINCETON® 65 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
10
PARTS LIST:
uDSP – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 * IC SMT HEX SCHMITT-T INV 74HC14
1 * IC SMT VREG +3.3V LM1117
1 * IC SMT CODEC TLC320AD77C
1 * IC SMT DSP TMS320VC5402PGE
1 * IC SMT VREG +1.8V 150mA TPS76318
1 * IC SMT RESET 5V MC34064D-5
1 * XTAL 20MHz HC49SD
PARTS LIST:
CHASSIS ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
9 0033206000 BUSHING KNOB SPACER
1 0021709000 BUSHING SR .437x.062x13/32 BLK
1 0057359000 CABLE RIBBON 2x8 7"
1 * CHASSIS PRINCETON 65 DSP
1 0054642000
**CONNECTOR IEC SNAP IN
1 0028560000 END BELL XFMR 85w
1 0048384000
**FUSE 20MMX5MM F2A 250V
100V/120V models only
1 0020789000
**FUSE QA 20mmx5mm 250v 1A
220V/230V models only
1 0013112000
**FUSE TD 20mmx5mm 250v 1A
240V Australia model only
1 0054318000 HEATSINK BAR PRNCTON 65/DLX 90
1 0054798000 JEWEL ASSY LED
9 0054419000 KNOB ROTARY 180 SS W/CHR INS
1 0057256000 KNOB ROTARY ARROW W/CHRM INSRT
1 * LABEL GROUNDING SEMKO
0 * LABEL VOLTAGE 100V
0 * LABEL VOLTAGE 230V
1 * LABEL VOLTAGE 240V
4 0028591000 NUT ACORN 8-32
4 0053479000 NUT HEX 7/16 20X1/8 NI
1 0031625000 NUT HOLDER PILOT LIGHT 1/16-27
1 0057421000 PANEL FRONT PRINCETON 65 DSP
1 * PANEL REAR PRINCETON 65 DSP
1 * PANEL REAR PRINCETON 65 DSP ROK 220V ROK model only
1 0057801008 PCB ASSY MICRO DSP
1 0057423000 PCB ASSY PRINCETON 65 DSP
1 0038900000 SCRW TF 6-32X1/4 PHP ZI
6 0028937000 SCRW TF 6-32x5/8 PHP ZI TAPTYT
3 0028500000 SCRW TF 8-32x3/4 HWH SLTD Z1
6 0025936000 STANDOFF NYL PCB SNAP 3/8" NAT
4 0053952000 STANDOFF NYLON BLK .250"
1 0039287000
**SWITCH DPST .187 TAB GLOBAL
4 0053480000 WASHER FLAT .442 X.692 NI
1 0054319000
**WIRE SET CHS PRINCETON 65
4 0030007000 WSHR LCK INTL 8x.330x.02 ZI
1 0027668000
**XFMR PWR 120v 85W
120V model only
1 0054824000
**XFMR PWR 65 WATT ANPS 230V
220V/230V/240V models only
1 0039357000
**XFMR PWR EXP DEL112/RP/PRN65
100V JPN model only
PARTS LIST:
CABINET ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
4 0019275000 INSERT GLIDE CUSHION 1.27 DIA
4 0019276000 GLIDE CAB 1.24x.335 NI
