PRINCETON® 65 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
11
PARTS LIST:
CABINET ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
2 0019279000 HANDLE CAP 2 HOLE NICKEL
8 0021972000 NUT T 10-32x3/4 STR 3 PRNG BLX
4 0022244000 SCRW M 10-32x1-1/8 OHP NI
4 0026566000 CORNER 2 HOLE w/TAB NI
2 0026568000 CORNER 3 HOLE NI
0.827 0026570000 TOLEX "BRAVURA BLACK"
10 0026571000 SCRW SMAB 8X5/8 THP NI
4 0026625000 SCRW WOOD 8x1 FH
7.186 0027502000 PARTICLEBOARD 3/4" THICKNESS
0.504 0027503000 PARTICLEBOARD 1/2" THICKNESS
0.01 0027648000 TAPE ALUM 6"x60YDS
1 0027846000 HANDLE 9.25" NO LOGO
0.194 0029085000 VELCRO STRIP LOOP 1.5"wd BLK
0.194 0029086000 VELCRO STRIP HOOK 1.5"wd BLK
1 0032524000 INSERT HANDLE
0.495 0037788000 CLOTH GRILLE BLACK/SILVER
0.048 0040677000 PLYWOOD BALTIC BIRCH 3/4"13PLY
PARTS LIST:
END ITEM ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0040547000 CAB ASSY PRINCETON 112/65
1 0057414000 CHS ASSY PRINCETON 65 DSP 100V JPN 100V JPN model only
1 0057413000 CHS ASSY PRINCETON 65 DSP 120V DOM 120V model only
1 0057415000 CHS ASSY PRINCETON 65 DSP 230V 230V models only
1 0057416000 CHS ASSY PRINCETON 65 DSP 230V ROK 230V ROK model only
1 0057417000 CHS ASSY PRINCETON 65 DSP 240V AUS 240V AUS model only
1 0053997000
**CORD PWR W/IEC CONN 100V JPN
100V JPN model only
1 0047251000
**CORD PWR W/IEC CONN 230V
230V models only
1 0057674000
**CORD PWR W/IEC CONN 230V ARG
230V ARG model only
1 0047249000
**CORD PWR W/IEC CONN 230V UK
230V UK model only
1 0047250000
**CORD PWR W/IEC CONN 250V
240V AUS model only
1 0047248000
**CORD PWR W/IEC CONN DOM
110V/120V models only
.004rl * CORROSEAL 50# (12"X 250' ROLL)
1 * DECAL SPEAKER GLOBE ROUND
0 0057418000 MANUAL OWNERS PRINCETON 65 DSP
1 0029906000 NAMEPLATE FENDER GENERIC SMALL
4 0026577000 SCRW M 10-32x1 PHP BLX
6 0036199000 SCRW M 8-32x1-3/16 OHP BLX CP
2 0018113000 SCRW SMA 4x1/2 OHP BLX
2 0011678000 SCRW SMA 8x1-1/2 OHP BLX
1 0025923000 SPKR 12" 8 OHM 75W(099-4812-005)
0 0057419000 SVC DIAG COMB PRINCETON 65 DSP
8 0029527000 WSHR FNSH 8-5/8 FLNGD BLX WX
