Fender Princeton 65 DSP Service Manual

PRINCETON® 65 DSP
(This is the model name for warranty claims)
3
SPECIFICATIONS
Model Name: Princeton 65 DSP
Release Number: PR 403
(Not a model number)
Part Numbers (120V, 60Hz) US: 2267400030
(110V, 60Hz) TW: 2267401030
(240V, 50Hz) AUS: 2267403030
(230V, 50Hz) UK: 2267404030
(230V, 50Hz) ARG: 2267405030
(230V, 50Hz) EUR: 2267406030
(100V, 50/60Hz) JPN: 2267407030
(220V, 60Hz) ROK: 2267409030
Power Requirement: 180W
Power Output: 65 W RMS into 8 ohms @ 5 %THD
Power Amp Sensitivity: 620mV for 65W into 8 ohms @ 5 %THD
Impedances Input (Pre-Amp): >1M ohms
Pre Amp Out: 1k ohms
Pwr Amp In: 10k ohms
Speaker Complement: One (1) 12”, 8 ohm,
Fender Special Design Speaker
(P/N 0025923000)
Dimensions Height: 16.5 in (41.9 cm)
Width: 18.6 in (47.3 cm)
Depth: 9 in (22.9 cm)
Weight: 28 lbs. (12.7 kg)
Product specifications are subject to change without notice
