Fender Princeton 65 DSP Service Manual

PRINCETON® 65 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
6
PARTS LIST: MAIN – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0057423000
**PCB ASSY PRINCETON 65 DSP
1 * PCB FAB PRINCETON 65
1 0048451000 BUTTON PUSH OFF WHITE At S1
1 0050687000 CABLE JMPR 6 CKT .156 ROUND PW1
2 0038689001 CAP AE AX .47uF 100V 20% C15-16
1 0025960001 CAP AE AX 22uF 16V 20% C40
6 0028463003 CAP AE RDL 10uF 50V 20% C35-36 C57 C61 C81 C90
2 0028458003 CAP AE RDL 1uF 50V 20% C49 C93
4 0028459003 CAP AE RDL 2.2uF 50V 20% C7 C17 C48 C50
2 0041048000 CAP AE RDL 2200uF 50V 20% C65-66
5 0028467003 CAP AE RDL 22uF 50V 20% C9-10 C30 C32-33
1 0028489000 CAP AE RDL 470uF 50V 20% C59
4 0028471003 CAP AE RDL 47uF 50V 20% C53-54 C69-70
4 0038703001 CAP CA .1uF 50V 10% C63 C89 C92 C94
1 0039263001 CAP CA 1000pF 50V 5% C3
1 0038699001 CAP CA 100pF 100V 5% C6
1 0039255001 CAP CA 10pF 100V 5% C45
1 0039265001 CAP CA 2200pF 100V 5% C8
4 0039259001 CAP CA 220pF 100V 5% C29 C44 C67 C95
2 0039268001 CAP CA 4700pF 50V 5% C1-2
3 0038701001 CAP CA 470pF 50V 5% C14 C31 C60
2 0039256001 CAP CA 68pF 100V 5% C39 C91
11 0034788003 CAP CD .1uF 50V 20% .15" cut C71-78 C80 C85-86
1 0051457003 CAP CD 100pF 500V 5% C26
2 0051406003 CAP CD 220pF 500V 10% C51-52
1 0051458003 CAP CD 470pF 500V 10% C19
1 0051459003 CAP CD 560pF 500V 10% C21
5 0027255003 CAP MPF .001uF 100V 10% C34 C37-38 C83-84
1 0027264003 CAP MPF .01uF 100V 10% C43
2 0027270003 CAP MPF .033uF 100V 10% C87-88
1 0053860000
**CAP MPF .1UF 275V 10%
C79
1 0052003003
**CAP MPF .1UF 250V 10%
C64
1 0027278003 CAP MPF .1uF 63V 10% C23
2 0027281003 CAP MPF .22uF 63V 10% C5 C42
2 0027286003 CAP MPF .47uF 63V 10% C4 C62
1 0030960003 CAP PFF .1uF 50V 5% C56
1 0033578000 CAP PFF RDL .001uF 100V 10% C82
1 0033581003 CAP PFF RDL .0033uF 100V 10% C24
1 0033583003 CAP PFF RDL .0047uF 100V 10% C25
2 0030945003 CAP PFF RDL .01uF 50V 5% C46-47
1 0033590003 CAP PFF RDL .022uF 100V 10% C22
1 0030950003 CAP PFF RDL .022uF 50V 5% C28
3 0033591003 CAP PFF RDL .033uF 100V 10% C12-13 C18
1 0030953003 CAP PFF RDL .039uF 50V 5% C27
2 0033592003 CAP PFF RDL .047uF 100V 10% C11 C20
2 0037324000 CONTROL 100K 30C SNAP IN
R23 R43 DRIVE/ (DRIVE)TREBLE
1 0034720000 CONTROL 100KB SNAP IN
R33 (DRIVE)VOLUME
