PRINCETON® 65 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
7
PARTS LIST:
MAIN – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0049402000 CONTROL 25K B SNAPIN
R40 (DRIVE)BASS
3 0034719000 CONTROL 50KB SNAP IN
R9 R37 R57 (CLEAN)BASS, (DR)MID, FX LVL
1 0038658000 CONTROL RTRY 50K 30C
R8 (CLEAN)TREBLE
1 0037323000 CONTROL SNAPIN 50K 15A
R16 (CLEAN)VOLUME
5 0064089001 DIODE 1N4003 D14 D35-37 D56
31 0006260001 DIODE 1N4448 SIGNAL D1-5 D8-12 D15-16 D18-21 D24-28 D31-32 D40
D49-55
4 0020534000 DIODE 1N5402 RECTIFER 200v C&F D42-45
2 0025821001 DIODE HV FDH-400 SWITCHING LL D22-23
2 0054210001 DIODE SCHOTTKEY BAT85 D33-34
2 0031729001 DIODE ZEN 1n5231b.5w 5.1v 5% D29-30
2 0031635001 DIODE ZEN 1N5240B 10V 5% D17 D39
2 0028119060 DIODE ZEN 1N5353B 16V 5W 5% D46-47
1 0057928000 DIODE ZEN 1N5363B 30V 5W 5% D13
1 0041074000 ENCODER, 16 POS. BI S2
11 0025802000 FSTN TAB MALE .250x.032 PCB MT P1-5 P106-107 P109-110 P113-114
4 0026000001 FSTN TAB MALE PCB MT .187X.032 P105 P111-112 P115
2 0051094003
**FUSE CLIP PCB 5MM
F1
1 0057350000 HEADER 2X8 P6
1 0054320000 HEATSINK PLATE PRINCETON 65 At Q18-19
1 0025796000 HEATSINK TO-220 At U8
3 0016795000 IC DUAL OP AMP TL072 U1 U5 U7
5 0031611000 IC DUAL OPAMP PC4560 U2-4 U6 U10
1 0041812000 IC REGULATOR +5V MC7805CT U8
2 0040903000 INSULATOR MICA TO-218 At Q18-19
2 0051658000 JACK MONO R/A J3 J7
2 0053450000 JACK STEREO R/A J1 J4
102 0020888001 JUMPER WIRE 22 GA J1-102
1 0055812000 LED TULIP ASSEMBLY D48
3 0049948000 LED, RED LONG LEAD LUMEX D6-7 D41
1 0097360000 NUT HEX 4-40 EX LOCk At U8
2 0031900001 RES CF 1/2W 15k 5% R85 R88
1 0027869001 RES CF 1/2W 470ohm 5% R115
2 0026549001 RES CF 1/2W 5% 1.5Kohm R89 R92
1 0028842001 RES CF 1/4W 1.1Kohm 5% R4
2 0024970001 RES CF 1/4W 1.8k 5% R13 R73
12 0024997001 RES CF 1/4W 100k 5% R42 R49 R60 R67-68 R113 R126-129 R142-143
8 0024981001 RES CF 1/4W 10k 5% R111 R134-135 R137 R139 R141 R144-145
3 0024937001 RES CF 1/4W 10ohm 5% R93 R101 R19
1 0024953001 RES CF 1/4W 120 ohm 5% R84
1 0024985001 RES CF 1/4W 15k 5% R7
2 0025058001 RES CF 1/4W 180k 5% R12 R45
To Next Page
