Fender Princeton 65 DSP Service Manual

PRINCETON® 65 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
8
PARTS LIST: MAIN – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0024986001 RES CF 1/4W 18k 5% R64
6 0024965001 RES CF 1/4W 1k 5% R20 R61 R63 R136 R138 R153
9 0025069001 RES CF 1/4W 1M 5% R32 R62 R116-117 R131-133 R140 R148
10 0024971001 RES CF 1/4W 2.2k 5% R15 R54-56 R58 R95 R97-98 R100 R147
2 0029600001 RES CF 1/4w 200ohm 5% R86-87
1 0029006001 RES CF 1/4W 20k 5% R112
3 0025059001 RES CF 1/4W 220k 5% R14 R29 R69
7 0024987001 RES CF 1/4W 22k 5% R10-11 R21-22 R44 R108 R152
2 0024957001 RES CF 1/4W 270ohm 5% R96 R99
7 0024988001 RES CF 1/4W 27k 5% R18 R59 R71-72 R109-110 R146
4 0024973001 RES CF 1/4W 3.3k 5% R25-26 R52 R130
1 0024975001 RES CF 1/4W 3.9k 5% R65
3 0024989001 RES CF 1/4W 33k 5% R27 R35 R66
2 0024977001 RES CF 1/4W 4.7k 5% R79 R149
3 0028956001 RES CF 1/4W 43k 5% R36 R38 R50
1 0025065001 RES CF 1/4W 470k 5% R28
3 0024961001 RES CF 1/4W 470ohm 5% R34 R75-76
3 0024993001 RES CF 1/4W 47k 5% R30 R41 R74
2 0024947001 RES CF 1/4W 47ohm 5% R77-78
1 0028034001 RES CF 1/4W 5.1Kohm 5% R6
2 0024978001 RES CF 1/4W 5.6k 5% R53 R123
2 0028018001 RES CF 1/4W 510Kohm 5% R2-3
3 0024979001 RES CF 1/4W 6.8k 5% R5 R150-151
1 0025067001 RES CF 1/4w 680k 5% R70
2 0024995001 RES CF 1/4w 68k 5% R1 R39
1 0025942001 RES CF 1/4W 7.5Kohm 5% R17
1 0024980001 RES CF 1/4W 8.2k 5% R24
1 0029613001 RES CF 1/4W 91k 5% R31
1 0029722001 RES FILM 1W 1k 5% R114
2 0037354001 RES FILM 1W 4.7K 5% LL R90-91
5 0036960001 RES FUSE MF 1/4w 5% 47ohm T/R R81 R83 R94 R102 R104
1 0015582001 RES MF 1/4W 10k 1% R47
4 0027632001 RES MF 1/4W 2.43Kohm 1% R46 R51 R124-125
1 0016971001 RES MF 1/4W 33.2k 1% R48
2 0054208001 RES MF FUSE 1/4 5% 470ohm R80 R82
1 0051417001 RES MOX 2 W 22 OHM LL 5% R106
2 0041277001 RES MOX 2W 820 OHM 5% R120-121
1 0054434000 RES WW 5W 10% .1ohm R107
2 0027478000 RES WW BT 5w 10% .22 ohm R103 R105
1 0029670000 RES WW BT 5w 10% 150 ohm R122
2 0028037000 RES WW BT 5w 10% 330 ohm R118-119
1 0039420000 SCRW M 4-40X3/8 PHP SS SEMS At U8
4 0027638000 SCRW TF 4-40x3/8 HWHS ZI .1"HD At HS1
2 0032908000 SCRW TF 6-32x3/8 PHP ZI At HS1
