Fender Princeton 65 DSP Service Manual

PRINCETON® 65 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
9
PARTS LIST: MAIN – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0036178000 SPACER LED .5x.1 BRN A6192-1 At D41
1 0028091000 SWITCH PUSH SLFLK SHORT STROKE S1
1 0051418000
**THERMAL SENSOR PTC 100 DEG
RT1
1 0059694000
**WIRE SET PCB PRINCETON 65 DSP
At WJ1-2 P7-8
6 0014689003 XSTR N-CH JFET J111 TO-92(000) Q1-4 Q23 Q26
1 0016739003 XSTR NPN 2N4401 TO-92 Q12
1 0028760000 XSTR NPN 2SC4793 Q15
1 0051448003 XSTR NPN 2SD1857 Q14
1 0051725000 XSTR NPN MJW21192 TO 247 Q18
2 0014867003 XSTR NPN MPSW42 (TO-92) Q8 Q11
2 0025751003 XSTR NPN SILICON TO_92 Q6-7
5 0016742003 XSTR PNP 2N4403 TO-92 Q13 Q21-22 Q24-25
1 0028759000 XSTR PNP 2SA1837/2SA136A Q17
1 0051447003 XSTR PNP 2SB1236 Q16
1 0051724000 XSTR PNP MJW21191 TO 247 Q19
1 0014866003 XSTR PNP MPSW92 TO-226AE Q10
1 0025752003 XSTR PNP SILICON TO_92 Q9
REF 0025936000 STANDOFF NYL PCB SNAP 3/8” NAT At ST1-6
REF 0057419000 SVC DIAG COMB PRNCTN 65 DSP
PARTS LIST: uDSP – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0057801008
**PCB ASSY uDSP PRINCETON 65 DSP
w/ EPROM
REF 0057283000 SVC DIAG COMB MICRO DSP
1 0057802100 IC ROM PRINCETON 65 DSP V1.00
1 * PCB Fab u-DSP
2 * CAP 0805 CER .001uF 25V 5%
14 * CAP 0805 CER .01uF 25V 5%
10 * CAP 0805 CER .1uF 25V 5%
2 * CAP 0805 CER 22pF 25V 5%
2 * CAP 0805 CER 750Pf 25v 5%
3 * CAP 3528 TAN 4.7uF 16V 20%
6 * CAP 3528 TAN 10uF 16V 20%
5 * DIODE SMT 1N4448 SIGNAL
2 * HDR .1 CTR 8x2 CKT SQ PIN
4 * RES 0805 MF 1/10W 5% 0ohm
2 * RES 0805 MF 1/10W 5% 100ohm
4 * RES 0805 MF 1/10W 5% 750ohm
4 * RES 0805 MF 1/10W 5% 1k
1 * RES 0805 MF 1/10W 5% 2k
1 * RES 0805 MF 1/10W 5% 3.3k
2 * RES 0805 MF 1/10W 5% 4.7k
1 * RES 0805 MF 1/10W 5% 15k
1 * RES 0805 MF 1/10W 5% 47k
1 * IC SMT SOCKET PLCC 44-TT
1 * IC SMT TLC549 AD
1 * IC SMT SRAM 64Kx16
1 * IC SMT COUNTER 74LV4040
