1.2 Machine identification
Each machine is identified by a model and a serial number.
Record these numbers in the spaces given.
Give the model number and serial number to your dealer when parts or servicing are necessary.
Machine model number:
Machine serial number:
Date of delivery:
Dealer name:
Dealer address:
Dealer telephone number:
Dealer e-mail address:
Dealer fax number:
1.2.1 Serial number plate
Serial numbers identify the machine and are important if servicing or repair parts are necessary.
The machine serial number plate (1) is below the
cab on the right side.
1
HVJHE0110119301
Original art: /s/Creo Illustrate/Images/Josh/OPUS/1-18/serial number plate.svg
GUID-4A97FE30-7D29-4FE4-AC81-BD3F48656A70-low.svg [Low]
Fig. 1
GUID-0853B3F6-8A91-438A-9326-C54D60DEDBE0 [V5]
GUID-2DB508B9-ED3D-45EA-AC6D-4F2240C7A63D [V1]
1. General
IDEAL Series Combine 1-7
79037318C
