1.3.30.46 Reflector yellow
Reflector, yellow
Reflector, yellow
1.3.30.47 Reflector red
Reflector, red
Reflector, red
1.3.30.48 Reflector orange
Reflector, orange
Reflector, orange
1.3.31 Emergency exit
A hammer for emergency exit is above the right
control console. The hammer is to break the right
side glass to let you exit the cab in an emergency.
