FENDT IDEAL 9 Workshop Service Manual

1.4.15 Brake specifications
Brakes
IDEAL 7 IDEAL 8 IDEAL 9
Service brakes Left/right, wet multidisc with ball ramp actuation, non-boosted slave cylinders
and DOT 4 brake fluid in combination with hydrostatic
Location Transmission output shaft
Park brake Spring apply hydraulic release cylinder with push-pull cable, cable breakage
indicator and valve for controlled emergency braking
1.4.16 Wheel torque specifications
Front wheels
IDEAL 7 IDEAL 8 IDEAL 9
Wheel to final drive
flange
900 Nm (665 lbf ft)
Inner dual to outer dual 900 Nm (665 lbf ft)
Rear wheels
IDEAL 7 IDEAL 8 IDEAL 9
Standard rear axle (wheel
to hub)
750 Nm (550 lbf ft)
Rear wheel assist axle
(wheel to drive motor
flange)
750 Nm (550 lbf ft)
GUID-A37DAF53-EAF3-4E42-BBC0-74D9F24A0DFA [V3]
GUID-4296D2BF-8AD0-4F78-B91D-F527CA32567D [V3]
1. General
IDEAL Series Combine 1-75
79037318C
