1.2.8.4 LS pump identification
The identification plate (1) is on the front of the LS
pump.
GUID-4C3DDEEC-E6A8-4724-803F-B74527B647FE-high.jpg [High]
Fig. 13
1.2.8.5 Propel motor identification
The identification plate (1) is on the top part of the
propel motor.
1
HVJHE0110155701
Original art: /s/Creo Illustrate/Images/Josh/OPUS/1-18/New folder/701 plate.svg
GUID-D6BA93E1-D169-42FA-BC8B-906AB6BE26CA-low.svg [Low]
Fig. 14
1.2.8.6 Ground drive transmission identification
The identification plate (1) is on the front of the
ground drive transmission.
1
HVJHE0110155801
Original art: /s/Creo Illustrate/Images/Josh/OPUS/1-18/New folder/801 plate.svg
GUID-FDDD8436-BABE-4984-B66B-5120A98C1E11-low.svg [Low]
Fig. 15
