FENDT IDEAL 9 Workshop Service Manual

GUID-854FE760-5F4C-4246-A32E-B33F06F24358-high.jpg [High]
Fig. 80
Ref Description IDEAL 7 IDEAL 8 IDEAL 9
A Height 4000 mm (157.5 in)
B Tread width, front tires Standard 2490 mm to 3000 mm (98.0 in to 118.1 in)
ParaLevel 2690 mm to 2780 mm (105.9 in to 109.4 in)
Tread width, tracks 660.4 mm (26.0 in) 2630 mm (103.5 in)
762.0 mm (30.0 in) 2730 mm (107.5 in)
914.4 mm (36.0 in) 2870 mm (113.0 in)
C Width, outside of front
tires
Standard 3290 mm to 4000 mm (129.5 in to 157.5 in)
Standard with duals 5110 mm to 5460 mm (201.2 in to 215.0 in)
ParaLevel 3490 mm to 3680 mm (137.4 in to 144.9 in)
Width, outside of tracks 660.4 mm (26.0 in) 3290 mm (129.5 in)
762.0 mm (30.0 in) 3490 mm (137.4 in)
914.4 mm (36.0 in) 3790 mm (149.2 in)
D Tread width, rear tires 2270 mm to 3170 mm (89.4 in to 124.8 in)
1. General
IDEAL Series Combine 1-59
79037318C

FENDT IDEAL 9 Specifications

General

Brand	FENDT
Model	IDEAL 9
Category	Farm Equipment
Language	English
