Number Decal Description
33
Battery explosion and short circuits
Remove the negative cable(s) from the battery/batteries before you
remove the starter solenoid cover and before servicing the
electrical system.
34
Unloader drive
Make sure that there is a 1 mm to 2 mm distance between the nut
and the unloader drive hub.
35
Risk of unwanted movement
Install wheel chocks when you park or do work on the machine.
36
General safety alert
Each person in the operator cab must put on a seat belt before you
operate the machine.
37
Auto-Guide operation
Do not operate the Auto-Guide system when you move on roads.
38
General safety alert
Read and understand the Operator's Manual before you operate
the machine.
39
General safety alert
Stop the engine, remove the ignition key and make sure that all
components stop. Read the Operator's Manual before you do the
maintenance or repair work on the machine.
4
1. Safety
IDEAL Series Combine 47
ACX2738370
