6 Fendt Vario 700, 800, and 900 Series SmarTrax™ MD Installation Manual
Bolt - #10-24 x 3/4” UNC Zinc Carriage 311-0069-082 2
Bolt - 5/16”-18 x 3/4” Grade 2 Carriage 311-0069-111 2
Nut - 3/8”-16 Zinc Flanged Lock 312-1001-167 3
Nut - 5/16”-18 Zinc Flanged Lock 312-1001-184 2
Nut - #10-24 Wing 312-3000-013 2
Washer - 0.265” ID x 0.505” OD x 0.060”
Thick
313-2300-120 4
Tape - 3” Double-Sided 332-0000-019 6
TABLE 2. SmarTrax MD Controller Kit (P/N 117-5030-020)
Picture Item Description Part Number Qty.
Not Pictured
Manual - SmarTrax MD Calibration &
Operation
016-5030-020 1
Not Pictured
Sheet - Field Computer Minimum Software
Installation
016-5030-023 1
Assembly - SmarTrax MD Mechanical Drive
Unit
063-4001-010 1
TABLE 1. SmarTrax MD Installation Kit (P/N 117-5030-043)
Picture Item Description Part Number Qty.

FENDT Vario 936 Specifications

General

Max Speed	60 km/h
Hydraulic System	Closed-center load sensing
Rated engine speed	2100 rpm
Tire Size (Rear)	650/65 R42
Transmission	CVT
Fuel Tank Capacity	660 liters
Engine	MAN
Wheelbase	3, 050 mm (120 inches)
Engine Power	360 hp (268 kW)
