FENDT Vario 936 User Manual

Manual No. 016-5030-043 Rev. A 11
Mechanical Drive Installation
Install the Anti-Rotation Bracket
FIGURE 5. Steering Column Cover
1. Remove the control arm cover.
Note: Keep the control arm cover for future use.
FIGURE 6. Bolt Removal
2. Remove the bolts used to secure the control clamp to the steering column.
3. Remove the control clamp.
Note: Keep the control clamp for future use.

FENDT Vario 936 Specifications

General

Max Speed	60 km/h
Hydraulic System	Closed-center load sensing
Rated engine speed	2100 rpm
Tire Size (Rear)	650/65 R42
Transmission	CVT
Fuel Tank Capacity	660 liters
Engine	MAN
Wheelbase	3, 050 mm (120 inches)
Engine Power	360 hp (268 kW)
