Feniex Fusion - Rear Mounting Instructions; Child Restraint Bracket Removal; Mounting Bracket Attachment

V2.0
TM
FENIEX. 2017 INSTRUCTION MANUAL
WEB. www.feniex.com
8
Rear Mounting Instructions
Step 1: Following OEM instructions, remove
the child restraint brackets on the passenger
and driver side of the vehicle. Retain the
hardware and the child restraint bracket.
Step 2: Secure each mounting bracket to
the metal frame using the provided 1/4“x 20
hex head bolts. Insert the hex head bolts
through the bottom holes on each side to
fasten the light bar frame to the mounting
brackets (See page 13 for vehicle specic
bracket diagram).
Step 3: Position the opening of each
bracket directly under the mounting location
for the removed child restraint bracket.
Certications:
CE Certied
SAE J595 Certied
Meets CCR, Title 13 Requirements
Fusion Specications
Voltage: 9-13 VDC
Power < 5 Amps
Dimensions: 0.93″H x 37″W x 5.5″H
Charger Full
Rear Model
Shown (upside
down)
Passenger
Bracket
Driver
Bracket
