FERNO/MAN/01/18/159/UK 15 Pegasus Trolley
To return the trolley to normal length, lift the folded head end and the spring
loaded knurled sleeves will return to their locked position. Adjust the backrest
as necessary.
Hold the foot pedal down and lower the trolley.
Foot End Fold Down (PTS version only)
Stand at the foot end of the trolley and grasp the two knurled sleeves, located
one each side of the trolley frame.
Depress the spring loaded pins, which are positioned underneath each sleeve.
This will allow each sleeve to be pushed along the frame, thus releasing the
foot end of the frame to drop down.
The foot end tray can now be shortened by simply pulling out the spring
loaded knob and folding the tray down.
Stow the push/pull handle below the lock-bracket. Do not raise the trolley
top when in this condition.
The trolley is now ready for use as a seat base within the Patient Transport
Vehicle.
To return the trolley to its normal length, the reverse procedure should be
applied: raise the lowered foot end to its horizontal position and slide both
sleeves back over the hinged positions until they lock in position. The trolley is
now ready for use normally.
Wheels
All wheels have a braking system ensuring that the castor wheel will neither roll nor
rotate when the brake lever is applied. A minimum of two brakes should be engaged
whenever a patient is being transferred onto or off the trolley.
IMPORTANT:
When using as a seat base the length reduction feature at the foot end
MUST BE FOLDED DOWN.
Thus enabling seating for a maximum of three persons (total weight 200 kg)
IMPORTANT
When changing from PTS vehicle position, with the fold down frame
locked into its normal position, ensure the push/pull handle does not
interfere with the foot end floor lock bracket
