FERRI TKD - Technical Specifications; Hydraulic System

7
2.2 Technical specifications (Tab. 1)
TAB. 1
FLAIL HEDGE MOWER MOD.
TKD 54
Min. tractor required power HP (Kw) 90/100 (74/66)
Min. tractor required weight Kg. (lbs) 4400 (9500)
PTO speed rpm 1000
Voltage of the electrical system volt 12
Max. absorbed power HP (Kw) 73 (53)
Standard weight of the machine Kg. (lbs) 1645 (3553)
Attachment to the tractor Cat. II
HYDRAULIC SYSTEM
Hydraulic oil Lt (gal) 105
Intake filter micron 10
Return filter micron 30
Max. arm pressure Bar (PSI) 200 (3300)
Max. flail head pressure Bar (PSI) 280 (4060)
FLAIL HEAD
MOD.
TNP 125 TNCD 120
Width of cut Cm (in) 125 (49) 110 (43)
Flail head weight Kg. (lbs) 386 (833) 325 (715)
Head movement ° 235°
Rotor speed rpm 3000
Multi-use flails N. 44+22 36+18
Articulated “Y” flails N. 60+30 48+24
Hammer blades N. 22 18
