4.4 Troubleshooting
Diagnostics
In case of operation faults or problems, the display flashes and the fault identification
code appears.
There are faults that cause permanent shutdown (marked with the letter “A”): to restore
operation just press the reset button (detail 6 -fig. 1) for 1 second or RESET on the op-
tional remote timer control if installed; if the boiler fails to start, it is necessary to firstly
eliminate the fault.
Faults marked with the letter “F” cause temporary shutdowns that are automatically reset
as soon as the value returns within the boiler's normal working range.
Table of faults
Table. 8 - List of faults
Fault
code
Fault Possible cause Cure
A01
No burner ignition
No gas
Check the regular gas flow to the
boiler and that the air has been
eliminated from the pipes
Ignition/detection electrode fault
Check the wiring of the electrode and
that it is correctly positioned and free
of any deposits
Faulty gas valve
Check the gas valve and replace it if
necessary
Insufficient gas supply pressure Check the gas supply pressure
Trap blocked
Check the trap and clean it if
necessary
A02
Flame present signal with
burner off
Electrode fault Check the ionisation electrode wiring
Card fault Check the card
A03
Overtemperature protection
intervention
Heating sensor damaged
Check the correct positioning and
operation of the heating sensor
No water circulation in the
system
Check the circulating pump
Air in the system Vent the system
A04
Fume extraction duct safety
device intervention
Fault F07 generated 3 times in
the last 24 hours
See fault F07
A05 Fan protection activated
Fault F15 generated for 1 hour
(consecutive)
See fault F15
A06
No flame after ignition stage
(6 times in 4 minutes)
Ionisation electrode fault Check the position of the ionisation
electrode and replace it if necessary
Flame unstable Check the burner
Gas valve Offset fault Check the Offset adjustment at
minimum power
air/fume ducts obstructed
Remove the obstruction from the flue,
fume extraction ducts and air inlet
and terminals
Trap blocked
Check the trap and clean it if
necessary
F07 High fume temperature
The fume probe detects an
excessive temperature
Check the exchanger
F10 Delivery sensor 1 fault
Sensor damaged
Check the wiring or replace the sensor Wiring shorted
Wiring disconnected
F11 Return sensor fault
Sensor damaged
Check the wiring or replace the sensor Wiring shorted
Wiring disconnected
F12 DHW sensor fault
Sensor damaged
Check the wiring or replace the sensor Wiring shorted
Wiring disconnected
F13 Fume probe fault
Probe damaged
Check the wiring or replace the fume
probe
Wiring shorted
Wiring disconnected
F14 Delivery sensor 2 fault
Sensor damaged
Check the wiring or replace the sensor Wiring shorted
Wiring disconnected
F15 Fan fault
No 230V power supply Check the 8-pin connector wiring
Tachometric signal interrupted Check the 8-pin connector wiring
Fan damaged Check the fan
F34 Supply voltage under 170V Electric mains trouble Check the electrical system
F35 Faulty mains frequency Electric mains trouble Check the electrical system
F37
Incorrect system water pres-
sure
Pressure too low Fill the system
Water pressure switch damaged
or not connected
Check the sensor
F39 External probe fault
Probe damaged or wiring shorted
Check the wiring or replace the sensor
Probe disconnected after activat-
ing the sliding temperature
Reconnect the external probe or
disable the sliding temperature
A41
A44
Sensor positioning
Heating sensor detached from
pipe
Check the correct positioning and
operation of the heating sensor
A42 Heating sensor fault Sensor damaged Replace the sensor
F43
Exchanger protection inter-
vention.
No system H
2
O circulation
Check the circulating pump
Air in the system Vent the system
F52 Heating sensor fault Sensor damaged Replace the sensor
A61 Controller fault ABM03C Controller internal error ABM03C
Check the earth connection and
replace the controller if necessary.
A62
No communication between
controller and gas valve
Controller not connected
Connect the controller to the gas
valve
Valve damaged Replace the valve
A63
F64
A65
F66
Controller fault ABM03C Controller internal error ABM03C
Check the earth connection and
replace the controller if necessary.
A23
A24
F20
F21
A26
F40
F47
Card parameter fault Wrong card parameter setting
Check the card parameter and mod-
ify it if necessary.
Fault
code
Fault Possible cause Cure
