Ferroli BLUEHELIX TECH S 45H Instructions For Use, Installation And Maintenance

BLUEHELIX TECH S 45H
40
EN
5. TECHNICAL DATA AND CHARACTERISTICS
Table. 9 - Legend - figures cap. 5
5.1 General view
fig. 26 - General view
5.2 Diagrams
fig. 27 - Circulating pump head / pressure losses
A = Boiler pressure losses - 1 = Circulating pump min. speed - 2 = Cir-
culating pump max. speed
5.3 Hydraulic circuit
fig. 28 - Hydraulic circuit
5.4 Technical data table
7 Gas inlet - Ø 1/2” 138 External probe (optional)
10 System delivery - Ø 3/4” 139 Remote timer control (optional)
11 System return - Ø 3/4” 154 Condensate drain pipe
14 Pressure relief valve 155 Hot water tank temperature probe
16 Fan 186 Return sensor
22 Main burner 191 Fume temperature sensor
32 Heating circulating pump 193 Trap
36 Automatic air vent 196 Condensate tray
44 Gas valve 256 Modulating heating circulating pump signal
72 Room thermostat (not supplied) 278 Double sensor (Safety + Heating)
81 Ionisation/ignition electrode
95 Diverter valve (not supplied) A Auxiliary contact
104 Fuse
114 Water pressure switch
193
32
114
14
36
186
81
95
278
10 7 1144
191
196
22
16
0
1
2
3
4
5
6
7
0 500 1.000 1.500 2.000
Q [l/h]
H [m H
2
O]
A
8
9
C
B
2.500
Data Unit BLUEHELIX TECH S 45H
Max. heating capacity kW 43.0 (Q)
Min. heating capacity kW 7.5 (Q)
Max. Heat Output in heating (80/60°C) kW 4 (P)
Min. Heat Output in heating (80/60°C) kW 7.3 (P)
Max. Heat Output in heating (50/30°C) kW 4
Min. Heat Output in heating (50/30°C) kW 8.1
Gas supply pressure G20 mbar 20
Max. gas flow G20
m
3
/h
4.
Min. gas flow G20
m
3
/h
0.
CO
2
max. G20 %
9.0
CO
2
min. G20 %
8.0
Gas supply pressure G31 mbar 37
Max. gas flow G31 kg/h

Min. gas flow G31 kg/h 0.
CO
2
max. G31 %
10.
CO
2
min. G31 %
9.
Efficiency class Directive 92/42 EEC -
NOx emissions class - 5 (NOx)
Max. working pressure in heating bar 4.5 (PMS)
Min. working pressure in heating bar 0.8
Max. heating temperature °C 90 (tmax)
Heating water content litres 
Protection rating IP X5D
Power supply voltage V/Hz 230V/50Hz
Electrical power input W 1
Empty weight kg

Type of unit C13-C23-C33-C43-C53-C63-C83-B23-B33
PIN CE 0461CM0988
10 11
14
114
186
278
36
193
154
32
cod. 3541G102 - Rev. 0 - 0/2016
