TECHNICAL SPECIFICATIONS AND STANDARD PERFORMANCES - IR COOLING UNIT ONLY
Tw= Outlet water temperature °C kWf = refrigerating power (kW). kWa = Power input of compressors (kW)
The standard performances refer to a 5°C temperature difference between the water entering and leaving the plate-type heat exchanger and to operation of the unit
with all fans at top speed. A 0.44 x 10
-4
m
2
K/W fouling factor has also been considered with the unit installed at zero meters above sea level (Pb = 1013mbar).
Mod. 115-200
MOD. Tw
OUTDOOR AIR TEMPERATURE (°C D.B.)
20 25 30 35 40 45 50
kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa
115
5
128 24.9 119 28.7 113 31.6 106 34.8 98.5 38.4 91.3 41.8 83.8 45.2
6
131 25.1 123 28.9 116 31.9 109 35.1 101 38.7 93.8 42.2 86.1 45.7
7
135 25.4 126 29.2 119 32.2 112 35.5 104 39.1 96.5 42.7 88.6 46.1
8
139 25.7 130 29.5 123 32.6 115 35.9 107 39.6 99.2 43.1 - -
9
143 25.9 133 29.8 126 32.9 118 36.3 110 40.0 102 43.6 - -
10
147 26.2 137 30.1 129 33.2 121 36.6 113 40.4 105 44.0 - -
11
150 26.5 140 30.4 133 33.5 125 37.0 116 40.7 107 44.4 - -
12
154 26.7 144 30.7 136 33.9 128 37.3 119 41.1 110 44.9 - -
130
5
144 28.4 134 32.7 127 36.0 119 39.7 111 43.8 103 47.7 94.3 51.6
6
148 28.7 138 33.0 130 36.4 122 40.1 114 44.2 106 48.2 96.9 52.1
7
152 29.0 142 33.3 134 36.7 126 40.5 117 44.6 109 48.7 100 52.6
8
156 29.3 146 33.7 138 37.1 130 40.9 121 45.1 112 49.2 - -
9
161 29.6 150 34.0 142 37.5 133 41.4 124 45.6 115 49.7 - -
10
165 29.9 154 34.4 146 37.9 137 41.8 127 46.0 118 50.2 - -
11
169 30.2 158 34.7 149 38.3 140 42.2 130 46.5 121 50.7 - -
12
174 30.5 162 35.1 153 38.6 144 42.6 134 46.9 124 51.2 - -
145
5
163 31.6 152 36.3 144 40.0 135 44.1 126 48.6 117 53.0 107 57.3
6
168 31.9 157 36.7 148 40.4 139 44.5 129 49.1 120 53.5 110 57.9
7
173 32.2 161 37.0 152 40.8 143 45.0 133 49.6 123 54.1 113 58.5
8
178 32.6 166 37.5 157 41.3 147 45.5 137 50.1 127 54.7 - -
9
182 32.9 170 37.8 161 41.7 151 46.0 141 50.6 130 55.2 - -
10
187 33.2 175 38.2 165 42.1 155 46.4 144 51.2 134 55.8 - -
11
192 33.5 179 38.6 170 42.5 159 46.9 148 51.7 137 56.3 - -
12
197 33.9 184 39.0 174 42.9 163 47.3 152 52.2 141 56.9 - -
160
5
180 35.4 168 40.8 159 44.9 149 49.5 139 54.6 129 59.5 118 64.3
6
185 35.8 173 41.2 164 45.3 154 50.0 143 55.1 132 60.1 122 64.9
7
191 36.1 178 41.6 168 45.8 158 50.5 147 55.7 136 60.7 125 65.6
8
196 36.5 183 42.0 173 46.3 162 51.1 151 56.3 140 61.4 - -
9
202 36.9 188 42.5 178 46.8 167 51.6 155 56.8 144 62.0 - -
10
207 37.3 193 42.9 183 47.2 171 52.1 159 57.4 148 62.6 - -
11
212 37.6 198 43.3 187 47.7 176 52.6 164 58.0 151 63.2 - -
12
218 38.0 203 43.7 192 48.2 181 53.1 168 58.5 156 63.8 - -
180
5
205 39.3 192 45.2 181 49.8 170 54.9 158 60.5 147 66.0 135 71.4
6
211 39.7 197 45.6 186 50.3 175 55.4 163 61.1 151 66.6 138 72.0
7
217 40.1 203 46.1 192 50.8 180 56.0 167 61.7 155 67.3 142 72.8
8
223 40.5 209 46.6 197 51.4 185 56.6 172 62.4 160 68.0 - -
9
230 40.9 214 47.1 203 51.9 190 57.2 177 63.0 164 68.7 - -
10
236 41.3 220 47.5 208 52.4 195 57.8 182 63.7 168 69.4 - -
11
242 41.7 226 48.0 213 52.9 200 58.3 186 64.3 173 70.1 - -
12
248 42.1 232 48.5 219 53.4 206 58.9 191 64.9 177 70.8 - -
200
5
228 44.1 213 50.7 202 55.9 189 61.6 176 67.9 163 74.0 150 80.0
6
235 44.5 219 51.2 207 56.4 194 62.2 181 68.5 167 74.7 154 80.8
7
241 44.9 225 51.7 213 57.0 200 62.8 186 69.2 172 75.5 158 81.6
8
248 45.4 232 52.3 219 57.6 206 63.5 191 70.0 177 76.3 - -
9
255 45.9 238 52.8 225 58.2 211 64.1 197 70.7 182 77.1 - -
10
262 46.3 244 53.3 231 58.7 217 64.8 202 71.4 187 77.8 - -
11
269 46.8 251 53.8 237 59.3 222 65.4 207 72.1 192 78.6 - -
12
276 47.2 258 54.4 244 59.9 229 66.0 213 72.8 197 79.4 - -
