35
Tw= Outlet water temperature in °C kWt = heating output (kW). kWa = Power input of compressors (kW)
The standard performances refer to a 5°C temperature difference between the water entering and leaving the plate-type heat exchanger, out-
door air with 87% relative humidity and to operation of the unit with all the fans to top speed. A 0.44 x 10-4 m2 K/W fouling factor has also
been considered with the unit installed at zero meters above sea level (Pb = 1013mbar).
NOTE
For air temperatures of less than 7°C, the heating capacity is declared without considering the effect of the defrosting, strictly cor-
related with the humidity in the outdoor air.
TECHNICAL SPECIFICATIONS AND STANDARD PERFORMANCES - IP HEAT PUMP UNITS
Standard performances in heating mode AS Low noise Unit
MOD. Tw
OUTDOOR AIR TEMPERATURE (°C D.B.)
-6 -2 2 6 9 12 15
kWt kWa kWt kWa kWt kWa kWt kWa kWt kWa kWt kWa kWt kWa
50
30 42.8 11.3 49.0 11.4 53.6 11.5 57.0 11.6 61.1 11.7 65.4 11.9 69.9 12.0
35 42.5 12.5 48.8 12.6 53.3 12.8 56.7 12.9 60.8 13.0 65.0 13.2 69.6 13.3
40 42.3 13.9 48.5 14.0 53.0 14.2 56.4 14.3 60.5 14.5 64.7 14.6 69.2 14.8
45 42.0 15.5 48.1 15.6 52.7 15.8 56.0 15.9 60.1 16.1 64.2 16.3 68.7 16.5
50 41.7 17.2 47.8 17.3 52.3 17.6 55.6 17.7 59.6 17.9 63.8 18.1 68.2 18.3
60
30 46.7 12.5 53.5 12.6 58.5 12.8 62.2 12.9 66.7 13.0 71.3 13.1 76.3 13.3
35 46.4 13.9 53.2 14.0 58.2 14.2 61.9 14.2 66.4 14.4 71.0 14.6 75.9 14.7
40 46.2 15.4 52.9 15.5 57.9 15.7 61.5 15.8 66.0 16.0 70.5 16.2 75.5 16.4
45 45.8 17.2 52.5 17.3 57.5 17.5 61.1 17.6 65.5 17.8 70.1 18.0 74.9 18.2
50 45.5 19.1 52.2 19.2 57.1 19.5 61.1 19.6 65.1 19.8 69.6 20.0 74.4 20.2
70
30 54.9 14.8 62.9 14.9 68.8 15.1 73.2 15.2 78.5 15.4 83.9 15.5 89.8 15.7
35 54.6 16.4 62.6 16.5 68.5 16.7 72.8 16.8 78.1 17.0 83.5 17.2 89.3 17.4
40 54.3 18.2 62.2 18.4 68.1 18.6 72.4 18.7 77.6 18.9 83.0 19.1 88.8 19.4
45 53.9 20.3 61.8 20.4 67.6 20.7 71.9 20.8 77.1 21.0 82.4 21.3 88.2 21.5
50 53.6 22.5 61.4 22.7 67.1 23.0 71.4 23.1 76.6 23.4 81.9 23.7 87.6 23.9
80
30 61.2 17.0 70.2 17.1 76.8 17.4 81.6 17.5 87.6 17.7 93.6 17.9 100.1 18.1
35 60.9 18.9 69.8 19.0 76.4 19.2 81.2 19.3 87.1 19.6 93.1 19.8 99.6 20.0
40 60.6 21.0 69.4 21.1 75.9 21.4 80.8 21.5 86.6 21.8 92.6 22.0 99.1 22.3
45 60.2 23.3 68.9 23.4 75.4 23.8 80.2 23.9 86.0 24.2 92.0 24.5 98.4 24.7
50 59.7 25.9 68.5 26.1 74.9 26.4 79.6 26.6 85.4 26.9 91.3 27.2 97.7 27.5
90
30 73.5 19.6 84.2 19.7 92.1 20.0 97.9 20.1 105 20.3 112 20.5 120 20.8
35 73.1 21.7 83.8 21.8 91.6 22.1 97.4 22.3 104 22.5 112 22.8 120 23.0
40 72.7 24.1 83.3 24.3 91.1 24.6 96.9 24.7 104 25.0 111 25.3 119 25.6
45 72.2 26.8 82.7 27.0 90.5 27.3 96.2 27.5 103 27.8 110 28.1 118 28.5
50 71.7 29.8 82.1 30.0 89.8 30.4 95.5 30.6 102 30.9 110 31.3 117 31.6
100
30 80.9 21.2 92.8 21.3 101 21.6 108 21.8 116 22.0 124 22.3 132 22.5
35 80.5 23.5 92.3 23.7 101 24.0 107 24.1 115 24.4 123 24.7 132 25.0
40 80.1 26.1 91.8 26.3 100 26.7 107 26.8 114 27.1 122 27.4 131 27.7
45 79.5 29.1 91.1 29.2 99.7 29.6 106 29.8 114 30.1 122 30.5 130 30.8
50 79.0 32.3 90.5 32.5 99.0 32.9 105 33.1 113 33.5 121 33.9 129 34.3
115
30 92.4 24.6 106 24.8 116 25.1 123 25.3 132 25.6 141 25.9 151 26.1
35 91.9 27.3 105 27.5 115 27.8 123 28.0 131 28.3 141 28.6 150 29.0
40 91.4 30.4 105 30.5 115 31.0 122 31.1 131 31.5 140 31.9 149 32.2
45 90.8 33.7 104 33.9 114 34.4 121 34.6 130 35.0 139 35.4 148 35.8
50 90.1 37.5 103 37.7 113 38.2 120 38.5 129 38.9 138 39.4 147 39.8
130
30 101 27.1 116 27.3 126 27.7 134 27.8 144 28.1 154 28.5 165 28.8
35 100 30.1 115 30.2 126 30.7 134 30.8 143 31.2 153 31.5 164 31.9
40 99.7 33.4 114 33.6 125 34.1 133 34.3 143 34.7 152 35.1 163 35.5
45 99.0 37.1 113 37.4 124 37.9 132 38.1 142 38.5 151 39.0 162 39.4
50 98.3 41.3 113 41.5 123 42.1 131 42.4 141 42.8 150 43.3 161 43.8
145
30 114 30.5 130 30.7 143 31.1 152 31.3 163 31.6 174 32.0 186 32.3
35 113 33.8 130 34.0 142 34.4 151 34.6 162 35.0 173 35.4 185 35.8
40 113 37.5 129 37.8 141 38.3 150 38.5 161 39.0 172 39.4 184 39.8
45 112 41.7 128 42.0 140 42.6 149 42.8 160 43.3 171 43.8 183 44.3
50 111 46.4 127 46.7 139 47.3 148 47.6 159 48.1 170 48.7 182 49.2
160
30 128 33.8 146 34.0 160 34.5 170 34.7 182 35.1 195 35.5 209 35.9
35 127 37.5 145 37.7 159 38.2 169 38.4 181 38.9 194 39.3 207 39.8
40 126 41.7 145 41.9 158 42.5 168 42.7 180 43.2 193 43.7 206 44.2
45 125 46.3 144 46.6 157 47.2 167 47.5 179 48.0 191 48.6 205 49.1
50 124 51.5 143 51.8 156 52.5 166 52.8 178 53.4 190 54.0 203 54.6
180
30 145 37.9 166 38.2 182 38.7 193 38.9 207 39.4 222 39.8 237 40.3
35 144 42.1 165 42.3 181 42.9 192 43.1 206 43.6 221 44.1 236 44.6
40 144 46.8 164 47.0 180 47.7 191 48.0 205 48.5 219 49.1 235 49.6
45 143 52.0 163 52.3 179 53.0 190 53.3 204 53.9 218 54.5 233 55.1
50 142 57.8 162 58.1 177 58.9 189 59.3 202 59.9 216 60.6 231 61.3
200
30 160 42.4 183 42.6 200 43.2 213 43.4 228 44.0 244 44.5 261 45.0
35 159 46.9 182 47.2 199 47.9 212 48.2 227 48.7 243 49.3 260 49.8
40 158 52.2 181 52.5 198 53.2 210 53.5 226 54.2 241 54.8 258 55.4
45 157 58.0 180 58.4 197 59.2 209 59.5 224 60.2 240 60.9 256 61.6
50 156 64.5 178 64.9 195 65.8 208 66.1 223 66.9 238 67.7 255 68.4
