(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Unit specification
Cooling capacity VR(1) 55.6 60.9 71.6 81.8 94.6 106 116 131 149 164 187 208 kW
Total power input VR (1) 15.8 17.8 20.8 24.6 27.1 30.3 34.1 38.9 43.2 48.5 53.8 60.3 kW
EER VR (1) 3.52 3.42 3.44 3.33 3.49 3.50 3.40 3.37 3.45 3.38 3.48 3.45 -
Water flow VR (1) 2.66 2.91 3.42 3.91 4.52 5.06 5.54 6.26 7.12 7.84 8.93 9.94 l/s
Water pressure drop VR (1) 45 55 52 43 43 43 43 42 42 42 63 62 kPa
Recovered heating capacity (1) 70.6 77.8 91.4 105 120 135 148 168 190 210 238 265 kW
Recovered water flow rate (1) 3.37 3.72 4.37 5.02 5.73 6.45 7.07 8.03 9.08 10.0 11.4 12.7 l/s
Recovered water pressure drop (1) 39 47 52 54 47 47 45 46 47 48 50 51 kPa
MODEL 50 60 70 80 90 100 115 130 145 160 180 200 UM
Type of recovery exchanger STAINLESS STEEL BRAZE PLATES /
Quantity 1 n°
Total water content of recovery exchangers 4.6 4.6 5.4 6.2 9.7 10.9 12.6 14.5 11.1 13.0 14.6 16.3 l
Max. operating pressure on wet side 600 kPa
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Recovery heat exchanger specifications
Low noise Unit AS
Unit specification
Cooling capacity VR(1) 55.6 60.9 71.6 81.8 94.6 106 116 131 149 164 187 208 kW
Total power input VR (1) 15.8 17.8 20.8 24.6 27.1 30.3 34.1 38.9 43.2 48.5 53.8 60.3 kW
EER VR (1) 3.52 3.42 3.44 3.33 3.49 3.50 3.40 3.37 3.45 3.38 3.48 3.45 -
Water flow VR (1) 2.66 2.91 3.42 3.91 4.52 5.06 5.54 6.26 7.12 7.84 8.93 9.94 l/s
Water pressure drop VR (1) 45 55 52 43 43 43 43 42 42 42 63 62 kPa
Recovered heating capacity (1) 70.6 77.8 91.4 105 120 135 148 168 190 210 238 265 kW
Recovered water flow rate (1) 3.37 3.72 4.37 5.02 5.73 6.45 7.07 8.03 9.08 10.0 11.4 12.7 l/s
Recovered water pressure drop (1) 39 47 52 54 47 47 45 46 47 48 50 51 kPa
MODEL 50 60 70 80 90 100 115 130 145 160 180 200 UM
Type of recovery exchanger STAINLESS STEEL BRAZE PLATES /
Quantity 1 n°
Total water content of recovery exchangers 4.6 4.6 5.4 6.2 9.7 10.9 12.6 14.5 11.1 13.0 14.6 16.3 l
Max. operating pressure on wet side 600 kPa
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Recovery heat exchanger specifications
Extra Low noise Unit AX
Unit specification
Cooling capacity VR(1) 55.6 60.9 71.6 81.8 94.6 106 116 131 149 164 187 208 kW
Total power input VR (1) 15.8 17.8 20.8 24.6 27.1 30.3 34.1 38.9 43.2 48.5 53.8 60.3 kW
EER VR (1) 3.52 3.42 3.44 3.33 3.49 3.50 3.40 3.37 3.45 3.38 3.48 3.45 -
Water flow VR (1) 2.66 2.91 3.42 3.91 4.52 5.06 5.54 6.26 7.12 7.84 8.93 9.94 l/s
Water pressure drop VR (1) 45 55 52 43 43 43 43 42 42 42 63 62 kPa
Recovered heating capacity (1) 70.6 77.8 91.4 105 120 135 148 168 190 210 238 265 kW
Recovered water flow rate (1) 3.37 3.72 4.37 5.02 5.73 6.45 7.07 8.03 9.08 10.0 11.4 12.7 l/s
Recovered water pressure drop (1) 39 47 52 54 47 47 45 46 47 48 50 51 kPa
MODEL 50 60 70 80 90 100 115 130 145 160 180 200 UM
Type of recovery exchanger STAINLESS STEEL BRAZE PLATES /
Quantity 1 n°
Total water content of recovery exchangers 4.6 4.6 5.4 6.2 9.7 10.9 12.6 14.5 11.1 13.0 14.6 16.3 l
Max. operating pressure on wet side 600 kPa
Total heat recovery unit (VR)
Recovery heat exchanger specifications
Standard Unit AB
TECHNICAL SPECIFICATIONS AND STANDARD PERFORMANCES - IR COOLING UNIT ONLY
