37
TECHNICAL SPECIFICATIONS AND STANDARD PERFORMANCES - IP HEAT PUMP UNITS
Tw= Outlet water temperature in °C kWf = refrigerating power (kW). kWa = Power input of compressors (kW)
The standard performances refer to a 5°C temperature difference between the water entering and leaving the plate-type heat exchanger and to operation of the unit
with all the fans to top speed. A 0.44 x 10
-4
m
2
K/W fouling factor has also been considered with the unit installed at zero meters above sea level (Pb = 1013mbar).
Mod. 50-100
Standard performances in cooling mode AX Extra low noise unit
MOD. Tw
OUTDOOR AIR TEMPERATURE (°C D.B.)
20 25 30 35 40 45 50
kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa
50
5
56.7 13.3 53.0 15.3 50.1 16.8 47.0 18.5 43.7 20.4 40.5 22.3 37.2 24.1
6
58.3 13.4 54.4 15.4 51.5 17.0 48.3 18.7 44.9 20.6 41.6 22.5 38.2 24.3
7
60.0 13.5 56.0 15.6 53.0 17.1 49.7 18.9 46.2 20.8 42.8 22.7 39.3 24.6
8
61.7 13.7 57.6 15.7 54.5 17.3 51.1 19.1 47.6 21.1 44.0 23.0 - -
9
63.4 13.8 59.2 15.9 56.0 17.5 52.5 19.3 48.9 21.3 45.3 23.2 - -
10
65.1 13.9 60.7 16.0 57.4 17.7 53.9 19.5 50.2 21.5 46.5 23.4 - -
11
66.7 14.1 62.3 16.2 58.9 17.9 55.3 19.7 51.4 21.7 47.6 23.7 - -
12
68.6 14.2 64.0 16.4 60.5 18.0 56.8 19.9 52.8 21.9 48.9 23.9 - -
60
5
61.8 14.6 57.6 16.8 54.5 18.5 51.2 20.4 47.6 22.5 44.1 24.5 40.5 26.5
6
63.5 14.7 59.2 16.9 56.0 18.7 52.6 20.6 48.9 22.7 45.3 24.7 41.6 26.8
7
65.3 14.9 61.0 17.1 57.6 18.9 54.1 20.8 50.3 22.9 46.6 25.0 42.8 27.0
8
67.2 15.0 62.7 17.3 59.3 19.1 55.6 21.0 51.8 23.2 47.9 25.3 - -
9
69.0 15.2 64.4 17.5 60.9 19.3 57.2 21.2 53.2 23.4 49.3 25.5 - -
10
70.8 15.3 66.1 17.7 62.5 19.5 58.7 21.5 54.6 23.6 50.6 25.8 - -
11
72.7 15.5 67.8 17.8 64.1 19.6 60.2 21.7 56.0 23.9 51.9 26.0 - -
12
74.6 15.6 69.7 18.0 65.9 19.8 61.8 21.9 57.5 24.1 53.3 26.3 - -
70
5
72.1 17.3 67.3 19.9 63.7 21.9 59.8 24.1 55.6 26.6 51.5 29.0 47.3 31.3
6
74.1 17.4 69.2 20.0 65.4 22.1 61.4 24.4 57.1 26.8 52.9 29.3 48.6 31.6
7
76.3 17.6 71.2 20.3 67.3 22.3 63.2 24.6 58.8 27.1 54.5 29.6 50.0 32.0
8
78.5 17.8 73.2 20.5 69.3 22.6 65.0 24.9 60.5 27.4 56.0 29.9 - -
9
80.6 18.0 75.3 20.7 71.2 22.8 66.8 25.1 62.1 27.7 57.5 30.2 - -
10
82.8 18.2 77.3 20.9 73.0 23.0 68.6 25.4 63.8 28.0 59.1 30.5 - -
11
84.9 18.3 79.2 21.1 74.9 23.2 70.3 25.6 65.4 28.2 60.6 30.8 - -
12
87.2 18.5 81.4 21.3 76.9 23.5 72.2 25.9 67.2 28.5 62.2 31.1 - -
80
5
79.6 19.6 74.3 22.5 70.2 24.8 65.9 27.4 61.3 30.2 56.8 32.9 52.2 35.5
6
81.8 19.8 76.3 22.7 72.2 25.0 67.7 27.6 63.0 30.4 58.4 33.2 53.6 35.9
7
84.1 20.0 78.5 23.0 74.3 25.3 69.7 27.9 64.8 30.8 60.1 33.5 55.2 36.2
8
86.5 20.2 80.8 23.2 76.4 25.6 71.7 28.2 66.7 31.1 61.8 33.9 - -
9
88.9 20.4 83.0 23.5 78.5 25.8 73.6 28.5 68.5 31.4 63.5 34.2 - -
10
91.3 20.6 85.2 23.7 80.6 26.1 75.6 28.8 70.3 31.7 65.1 34.6 - -
11
93.6 20.8 87.4 23.9 82.6 26.4 77.5 29.1 72.1 32.0 66.8 34.9 - -
12
96.1 21.0 89.7 24.2 84.9 26.6 79.6 29.3 74.1 32.3 68.6 35.3 - -
90
5
95.7 22.3 89.3 25.7 84.4 28.3 79.2 31.2 73.7 34.4 68.3 37.5 62.7 40.5
6
98.3 22.5 91.8 25.9 86.8 28.6 81.4 31.5 75.8 34.7 70.2 37.8 64.4 40.9
7
101 22.8 94.4 26.2 89.3 28.8 83.8 31.8 78.0 35.1 72.2 38.2 66.3 41.3
8
104 23.0 97.1 26.5 91.8 29.2 86.2 32.2 80.2 35.4 74.3 38.6 - -
9
107 23.2 100 26.7 94.4 29.5 88.5 32.5 82.4 35.8 76.3 39.0 - -
10
110 23.5 102 27.0 96.9 29.7 90.9 32.8 84.6 36.1 78.3 39.4 - -
11
113 23.7 105 27.3 99.3 30.0 93.2 33.1 86.7 36.5 80.3 39.8 - -
12
116 23.9 108 27.5 102 30.3 95.7 33.4 89.1 36.9 82.5 40.2 - -
100
5
106 25.0 99.2 28.7 93.8 31.7 88.0 34.9 81.9 38.5 75.9 42.0 69.7 45.4
6
109 25.2 102 29.0 96.4 32.0 90.5 35.2 84.2 38.8 78.0 42.3 71.6 45.8
7
112 25.5 105 29.3 99.2 32.3 93.1 35.6 86.6 39.2 80.2 42.8 73.7 46.3
8
116 25.8 108 29.6 102 32.6 95.7 36.0 89.1 39.7 82.5 43.3 - -
9
119 26.0 111 29.9 105 33.0 98.4 36.4 91.5 40.1 84.8 43.7 - -
10
122 26.3 114 30.2 108 33.3 101 36.7 94.0 40.5 87.0 44.1 - -
11
125 26.5 117 30.5 110 33.6 104 37.1 96.4 40.9 89.2 44.6 - -
12
128 26.8 120 30.8 113 34.0 106 37.4 99.0 41.3 91.7 45.0 - -
