24
TECHNICAL SPECIFICATIONS AND STANDARD PERFORMANCES - IR COOLING UNIT ONLY
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Desuperheater unit (VD)
Recovery heat exchanger specifications
Standard Unit AB
Unit specification
Cooling capacity VD(1) 55.6 60.9 71.6 81.8 94.6 106 116 131 149 164 187 208 kW
Compressor power input VD (1) 15.8 17.8 20.8 24.6 27.1 30.3 34.1 38.9 43.2 48.5 53.8 60.3 kW
Total power input VD (1) 17.6 19.6 22.6 26.4 30.7 33.9 37.7 42.5 48.6 53.9 61.0 67.5 kW
EER VD (1) 3.16 3.11 3.17 3.10 3.08 3.13 3.08 3.08 3.07 3.04 3.07 3.08 -
Water flow VD (1) 2.66 2.91 3.42 3.91 4.52 5.06 5.54 6.26 7.12 7.84 8.93 9.94 l/s
Water pressure drop VD (1) 45 55 52 43 43 43 43 42 42 42 63 62 kPa
Recovered heating capacity (1) 15.7 17.6 20.0 23.6 27.1 30.4 34.4 38.4 44.0 49.3 55.4 61.3 kW
Recovered water flow rate (1) 0.75 0.84 0.96 1.13 1.29 1.45 1.64 1.83 2.10 2.36 2.65 2.93 l/s
Recovered water pressure drop (1) 9 11 14 19 15 18 11 14 18 22 18 21 kPa
MODEL 50 60 70 80 90 100 115 130 145 160 180 200 UM
Type of recovery exchanger STAINLESS STEEL BRAZE PLATES /
Quantity 1 n°
Total water content of recovery exchangers 0.6 0.6 0.6 0.6 0.8 0.8 1.3 1.3 1.3 1.3 1.8 1.8 l
Max. operating pressure on wet side 600 kPa
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Recovery heat exchanger specifications
Low noise Unit AS
Unit specification
Cooling capacity VD(1) 54.0 59.1 69.4 79.4 91.7 102 113 127 145 159 181 202 kW
Compressor power input VD (1) 16.5 18.5 21.7 25.7 28.3 31.7 35.6 40.6 45.1 50.6 56.2 63.0 kW
Total power input VD (1) 18.3 20.3 23.5 27.5 31.9 35.3 39.2 44.2 50.5 56 63.4 70.2 kW
EER VD (1) 2.95 2.91 2.95 2.89 2.87 2.89 2.88 2.87 2.87 2.84 2.85 2.88 -
Water flow VD (1) 2.58 2.82 3.32 3.79 4.38 4.87 5.40 6.07 6.93 7.60 8.65 9.65 l/s
Water pressure drop VD (1) 43 52 49 41 41 40 41 40 40 40 59 58 kPa
Recovered heating capacity (1) 15.7 17.6 20.0 23.6 27.1 30.4 34.4 38.4 44.0 49.3 55.4 61.3 kW
Recovered water flow rate (1) 0.75 0.84 0.96 1.13 1.29 1.45 1.64 1.83 2.10 2.36 2.65 2.93 l/s
Recovered water pressure drop (1) 9 11 14 19 15 18 11 14 18 22 18 21 kPa
MODEL 50 60 70 80 90 100 115 130 145 160 180 200 UM
Type of recovery exchanger STAINLESS STEEL BRAZE PLATES /
Quantity 1 n°
Total water content of recovery exchangers 0.6 0.6 0.6 0.6 0.8 0.8 1.3 1.3 1.3 1.3 1.8 1.8 l
Max. operating pressure on wet side 600 kPa
(1): The data refer to: Water temperature: evaporator inlet :12°C - evaporator outlet: 7°C, Outdoor air temperature 35°C.
The data refer to: Water temperature: recovery inlet :40°C - recovery outlet: 45°C.
Recovery heat exchanger specifications
Extra Low noise Unit AX
Unit specification
Cooling capacity VD(1) 52.7 57.7 67.8 77.5 89.6 100 110 124 140 156 177 197 kW
Compressor power input VD (1) 16.9 19.1 22.2 26.5 27.5 32.7 36.8 42.0 46.1 51.7 58.0 65.0 kW
Total power input VD (1) 18.7 20.9 24.0 28.3 31.1 36.3 40.4 45.6 51.5 57.1 65.2 72.2 kW
EER VD (1) 2.82 2.76 2.83 2.74 2.88 2.75 2.72 2.72 2.72 2.73 2.71 2.73 -
Water flow VD (1) 2.52 2.76 3.24 3.70 4.28 4.78 5.26 5.92 6.69 7.45 8.46 9.41 l/s
Water pressure drop VD (1) 41 50 47 39 39 39 39 38 37 38 56 55 kPa
Recovered heating capacity (1) 15.7 17.6 20.0 23.6 27.1 30.4 34.4 38.4 44.0 49.3 55.4 61.3 kW
Recovered water flow rate (1) 0.75 0.84 0.96 1.13 1.29 1.45 1.64 1.83 2.10 2.36 2.65 2.93 l/s
Recovered water pressure drop (1) 9 11 14 19 15 18 11 14 18 22 18 21 kPa
MODEL 50 60 70 80 90 100 115 130 145 160 180 200 UM
Type of recovery exchanger STAINLESS STEEL BRAZE PLATES /
Quantity 1 n°
Total water content of recovery exchangers 0.6 0.6 0.6 0.6 0.8 0.8 1.3 1.3 1.3 1.3 1.8 1.8 l
Max. operating pressure on wet side 600 kPa
