TECHNICAL SPECIFICATIONS AND STANDARD PERFORMANCES - IR COOLING UNIT ONLY
Tw= Temperatura acqua in uscita in °C kWf = Potenza frigorifera netta(kW). kWa = Potenza assorbita dai compressori (kW)
Le prestazioni standard si riferiscono ad un differenza di 5 °C di temperatura tra acqua entrante ed uscente dallo scambiatore a piastre, e al funzionamento dell'unità con
tutti i ventilatori alla massima velocità. Si considera inoltre un fattore di sporcamento di 0.44 x 10
-4
m
2
K/W e l'unità posta a zero metri sul livello del mare (Pb = 1013mbar).
Standard performances AS Low noise unit
Mod. 50-100
MOD. Tw
OUTDOOR AIR TEMPERATURE (°C D.B.)
20 25 30 35 40 45 50
kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa
50
5
59.2 12.1 55.3 13.9 52.3 15.3 49.1 16.9 45.7 18.6 42.3 20.3 38.8 22.0
6
60.9 12.2 56.8 14.0 53.7 15.5 50.4 17.1 46.9 18.8 43.5 20.5 39.9 22.2
7
62.7 12.3 58.5 14.2 55.3 15.6 51.9 17.2 48.3 19.0 44.7 20.7 41.1 22.4
8
64.4 12.5 60.1 14.3 56.9 15.8 53.4 17.4 49.7 19.2 46.0 20.9 - -
9
66.2 12.6 61.8 14.5 58.4 16.0 54.8 17.6 51.0 19.4 47.3 21.1 - -
10
68.0 12.7 63.4 14.6 60.0 16.1 56.3 17.8 52.4 19.6 48.5 21.4 - -
11
69.7 12.8 65.1 14.8 61.5 16.3 57.7 17.9 53.7 19.8 49.8 21.6 - -
12
71.6 13.0 66.8 14.9 63.2 16.4 59.3 18.1 55.2 20.0 51.1 21.8 - -
60
5
64.8 13.5 60.5 15.6 57.2 17.2 53.7 18.9 50.0 20.9 46.3 22.7 42.5 24.6
6
66.6 13.7 62.2 15.7 58.8 17.3 55.2 19.1 51.3 21.1 47.6 23.0 43.7 24.8
7
68.6 13.8 64.0 15.9 60.5 17.5 56.8 19.3 52.8 21.3 48.9 23.2 45.0 25.1
8
70.5 14.0 65.8 16.1 62.2 17.7 58.4 19.5 54.3 21.5 50.3 23.4 - -
9
72.5 14.1 67.6 16.2 64.0 17.9 60.0 19.7 55.8 21.7 51.7 23.7 - -
10
74.4 14.2 69.4 16.4 65.7 18.1 61.6 19.9 57.3 21.9 53.1 23.9 - -
11
76.3 14.4 71.2 16.5 67.3 18.2 63.2 20.1 58.8 22.2 54.4 24.2 - -
12
78.4 14.5 73.1 16.7 69.2 18.4 64.9 20.3 60.4 22.4 55.9 24.4 - -
70
5
76.1 15.9 71.1 18.3 67.2 20.1 63.1 22.2 58.7 24.5 54.3 26.7 49.9 28.8
6
78.2 16.0 73.0 18.4 69.1 20.3 64.8 22.4 60.3 24.7 55.8 26.9 51.3 29.1
7
80.5 16.2 75.2 18.6 71.1 20.5 66.7 22.6 62.1 25.0 57.5 27.2 52.8 29.4
8
82.8 16.4 77.3 18.8 73.1 20.8 68.6 22.9 63.8 25.2 59.1 27.5 - -
9
85.1 16.5 79.4 19.0 75.1 21.0 70.5 23.1 65.6 25.5 60.7 27.8 - -
10
87.3 16.7 81.5 19.2 77.1 21.2 72.3 23.3 67.3 25.7 62.3 28.1 - -
11
89.6 16.9 83.6 19.4 79.1 21.4 74.2 23.6 69.0 26.0 63.9 28.3 - -
12
92.0 17.0 85.9 19.6 81.2 21.6 76.2 23.8 70.9 26.2 65.7 28.6 - -
80
5
87.1 18.8 81.3 21.6 76.9 23.8 72.1 26.3 67.1 29.0 62.2 31.6 57.1 34.1
6
89.5 19.0 83.5 21.8 79.0 24.1 74.1 26.5 69.0 29.2 63.9 31.9 58.7 34.5
7
92.1 19.2 86.0 22.1 81.3 24.3 76.3 26.8 71.0 29.5 65.7 32.2 60.4 34.8
8
94.7 19.4 88.4 22.3 83.6 24.6 78.5 27.1 73.0 29.9 67.6 32.6 - -
9
97.3 19.6 90.9 22.5 85.9 24.8 80.6 27.4 75.0 30.2 69.5 32.9 - -
10
100 19.8 93.3 22.8 88.2 25.1 82.8 27.6 77.0 30.5 71.3 33.2 - -
11
102 20.0 95.6 23.0 90.4 25.3 84.9 27.9 79.0 30.8 73.1 33.5 - -
12
105 20.2 98.2 23.2 92.9 25.6 87.2 28.2 81.1 31.1 75.1 33.9 - -
90
5
101 20.7 94.0 23.8 88.9 26.2 83.4 28.9 77.6 31.9 71.9 34.8 66.0 37.6
6
103 20.9 96.6 24.0 91.3 26.5 85.7 29.2 79.7 32.2 73.9 35.1 67.8 37.9
7
106 21.1 99.4 24.3 94.0 26.8 88.2 29.5 82.1 32.5 76.0 35.4 69.8 38.3
8
109 21.3 102 24.6 96.6 27.1 90.7 29.8 84.4 32.9 78.2 35.8 - -
9
113 21.6 105 24.8 99.3 27.3 93.2 30.1 86.7 33.2 80.3 36.2 - -
10
115 21.8 108 25.0 102 27.6 95.7 30.4 89.0 33.5 82.4 36.6 - -
11
118 22.0 111 25.3 105 27.9 98.1 30.7 91.3 33.9 84.5 36.9 - -
12
122 22.2 114 25.5 107 28.1 101 31.0 93.8 34.2 86.8 37.3 - -
100
5
112 23.2 105 26.6 99.2 29.4 93.1 32.4 86.6 35.7 80.3 38.9 73.7 42.0
6
116 23.4 108 26.9 102 29.6 95.7 32.7 89.0 36.0 82.5 39.3 75.8 42.4
7
119 23.6 111 27.2 105 29.9 98.5 33.0 91.6 36.4 84.9 39.7 78.0 42.9
8
122 23.9 114 27.5 108 30.3 101 33.4 94.2 36.8 87.3 40.1 - -
9
126 24.1 117 27.7 111 30.6 104 33.7 96.8 37.1 89.7 40.5 - -
10
129 24.3 120 28.0 114 30.9 107 34.0 99.4 37.5 92.1 40.9 - -
11
132 24.6 123 28.3 117 31.2 110 34.4 102 37.9 94.4 41.3 - -
12
136 24.8 127 28.6 120 31.5 113 34.7 105 38.2 97.0 41.7 - -
