Tw= Outlet water temperature in °C kWf = refrigerating power (kW). kWa = Power input of compressors (kW)
The standard performances refer to a 5°C temperature difference between the water entering and leaving the plate-type heat exchanger and to operation of the unit
with all the fans to top speed. A 0.44 x 10
-4
m
2
K/W fouling factor has also been considered with the unit installed at zero meters above sea level (Pb = 1013mbar).
TECHNICAL SPECIFICATIONS AND STANDARD PERFORMANCES - IP HEAT PUMP UNITS
Mod. 115-200
MOD. Tw
OUTDOOR AIR TEMPERATURE (°C D.B.)
20 25 30 35 40 45 50
kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa
115
5
118 28.1 110 32.4 104 35.7 97.4 39.3 90.6 43.3 83.9 47.3 77.1 51.1
6
121 28.4 113 32.7 107 36.0 100 39.7 93.1 43.8 86.2 47.7 79.2 51.6
7
124 28.7 116 33.0 110 36.4 103 40.1 95.8 44.2 88.8 48.2 81.5 52.1
8
128 29.0 119 33.4 113 36.8 106 40.5 98.5 44.7 91.3 48.7 - -
9
131 29.3 123 33.7 116 37.1 109 40.9 101 45.1 93.8 49.2 - -
10
135 29.6 126 34.0 119 37.5 112 41.4 104 45.6 96.3 49.7 - -
11
138 29.9 129 34.4 122 37.9 115 41.8 107 46.0 98.7 50.2 - -
12
142 30.2 133 34.7 125 38.2 118 42.2 109 46.5 101 50.7 - -
130
5
131 31.7 123 36.5 116 40.2 109 44.3 101 48.9 93.7 53.3 86.1 57.6
6
135 32.0 126 36.8 119 40.6 112 44.7 104 49.3 96.3 53.8 88.4 58.1
7
139 32.3 130 37.2 123 41.0 115 45.2 107 49.8 99.1 54.3 91.0 58.7
8
143 32.7 133 37.6 126 41.4 118 45.7 110 50.4 102 54.9 - -
9
147 33.0 137 38.0 129 41.9 122 46.2 113 50.9 105 55.5 - -
10
151 33.4 141 38.4 133 42.3 125 46.6 116 51.4 107 56.0 - -
11
154 33.7 144 38.8 136 42.7 128 47.1 119 51.9 110 56.6 - -
12
159 34.0 148 39.1 140 43.1 131 47.5 122 52.4 113 57.1 - -
145
5
148 34.9 139 40.2 131 44.3 123 48.8 114 53.8 106 58.7 97.3 63.5
6
152 35.3 142 40.6 135 44.7 126 49.3 118 54.3 109 59.2 100 64.0
7
157 35.6 146 41.0 139 45.2 130 49.8 121 54.9 112 59.8 103 64.7
8
161 36.0 151 41.4 142 45.7 134 50.4 124 55.5 115 60.5 - -
9
166 36.4 155 41.9 146 46.1 137 50.9 128 56.1 118 61.1 - -
10
170 36.7 159 42.3 150 46.6 141 51.4 131 56.6 122 61.7 - -
11
175 37.1 163 42.7 154 47.0 145 51.9 135 57.2 125 62.3 - -
12
179 37.5 167 43.1 158 47.5 149 52.4 138 57.7 128 62.9 - -
160
5
166 39.6 154 45.5 146 50.2 137 55.3 128 61.0 118 66.5 109 71.9
6
170 39.9 159 46.0 150 50.6 141 55.8 131 61.5 121 67.1 112 72.5
7
175 40.4 163 46.4 155 51.2 145 56.4 135 62.2 125 67.8 115 73.3
8
180 40.8 168 46.9 159 51.7 149 57.0 139 62.9 128 68.5 - -
9
185 41.2 173 47.4 163 52.2 153 57.6 143 63.5 132 69.2 - -
10
190 41.6 177 47.9 168 52.8 157 58.2 146 64.1 136 69.9 - -
11
195 42.0 182 48.4 172 53.3 161 58.7 150 64.7 139 70.6 - -
12
200 42.4 187 48.8 177 53.8 166 59.3 154 65.4 143 71.3 - -
180
5
191 43.9 178 50.5 168 55.6 158 61.3 147 67.6 136 73.7 125 79.6
6
196 44.3 183 50.9 173 56.1 162 61.9 151 68.2 140 74.3 128 80.4
7
202 44.7 188 51.5 178 56.7 167 62.5 155 68.9 144 75.1 132 81.2
8
207 45.2 194 52.0 183 57.3 172 63.2 160 69.6 148 75.9 - -
9
213 45.7 199 52.5 188 57.9 176 63.8 164 70.3 152 76.7 - -
10
219 46.1 204 53.1 193 58.5 181 64.5 169 71.0 156 77.5 - -
11
224 46.6 209 53.6 198 59.0 186 65.1 173 71.7 160 78.2 - -
12
230 47.0 215 54.1 203 59.6 191 65.7 178 72.4 164 79.0 - -
200
5
212 49.7 198 57.2 187 63.1 176 69.5 164 76.6 152 83.6 139 90.3
6
218 50.2 204 57.8 193 63.7 181 70.2 168 77.4 156 84.3 143 91.2
7
225 50.7 210 58.4 198 64.3 186 70.9 173 78.1 160 85.2 147 92.1
8
231 51.3 216 59.0 204 65.0 191 71.7 178 79.0 165 86.1 - -
9
237 51.8 221 59.6 209 65.7 197 72.4 183 79.8 169 87.0 - -
10
244 52.3 227 60.2 215 66.3 202 73.1 188 80.6 174 87.9 - -
11
250 52.8 233 60.8 220 67.0 207 73.8 193 81.4 178 88.7 - -
12
257 53.3 239 61.4 226 67.6 213 74.6 198 82.2 183 89.6 - -
