Standard performances AX Extra low noise unit
Tw= Temperatura acqua in uscita in °C kWf = Potenza frigorifera netta(kW). kWa = Potenza assorbita dai compressori (kW)
Le prestazioni standard si riferiscono ad un differenza di 5 °C di temperatura tra acqua entrante ed uscente dallo scambiatore a piastre, e al funzionamento dell'unità con
tutti i ventilatori alla massima velocità. Si considera inoltre un fattore di sporcamento di 0.44 x 10
-4
m
2
K/W e l'unità posta a zero metri sul livello del mare (Pb = 1013mbar).
TECHNICAL SPECIFICATIONS AND STANDARD PERFORMANCES - IR COOLING UNIT ONLY
Mod. 50-100
MOD. Tw
OUTDOOR AIR TEMPERATURE (°C D.B.)
20 25 30 35 40 45 50
kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa kWf kWa
50
5
57.9 12.3 54.0 14.2 51.1 15.7 47.9 17.3 44.6 19.0 41.3 20.7 37.9 22.4
6
59.5 12.5 55.5 14.3 52.5 15.8 49.3 17.4 45.8 19.2 42.5 20.9 39.0 22.6
7
61.2 12.6 57.1 14.5 54.0 16.0 50.7 17.6 47.2 19.4 43.7 21.1 40.1 22.9
8
62.9 12.7 58.8 14.6 55.6 16.1 52.1 17.8 48.5 19.6 44.9 21.4 - -
9
64.7 12.9 60.4 14.8 57.1 16.3 53.6 18.0 49.8 19.8 46.2 21.6 - -
10
66.4 13.0 62.0 14.9 58.6 16.5 55.0 18.1 51.2 20.0 47.4 21.8 - -
11
68.1 13.1 63.6 15.1 60.1 16.6 56.4 18.3 52.5 20.2 48.6 22.0 - -
12
69.9 13.2 65.3 15.2 61.7 16.8 57.9 18.5 53.9 20.4 49.9 22.2 - -
60
5
63.4 14.0 59.1 16.1 55.9 17.7 52.5 19.5 48.8 21.5 45.2 23.5 41.5 25.4
6
65.1 14.1 60.8 16.2 57.5 17.9 53.9 19.7 50.2 21.7 46.5 23.7 42.7 25.6
7
67.0 14.2 62.5 16.4 59.1 18.0 55.5 19.9 51.6 21.9 47.8 23.9 43.9 25.9
8
68.9 14.4 64.3 16.6 60.8 18.2 57.1 20.1 53.1 22.2 49.2 24.2 - -
9
70.8 14.5 66.1 16.7 62.5 18.4 58.6 20.3 54.6 22.4 50.5 24.4 - -
10
72.7 14.7 67.8 16.9 64.1 18.6 60.2 20.5 56.0 22.6 51.9 24.7 - -
11
74.5 14.8 69.6 17.1 65.8 18.8 61.7 20.7 57.4 22.8 53.2 24.9 - -
12
76.6 15.0 71.5 17.2 67.6 19.0 63.4 20.9 59.0 23.1 54.6 25.1 - -
70
5
74.4 16.2 69.5 18.7 65.7 20.6 61.6 22.7 57.4 25.0 53.1 27.2 48.8 29.4
6
76.5 16.4 71.4 18.8 67.5 20.7 63.4 22.9 58.9 25.2 54.6 27.5 50.1 29.7
7
78.7 16.5 73.5 19.0 69.5 21.0 65.2 23.1 60.7 25.5 56.2 27.8 51.6 30.0
8
80.9 16.7 75.6 19.2 71.4 21.2 67.0 23.4 62.4 25.8 57.8 28.1 - -
9
83.2 16.9 77.6 19.4 73.4 21.4 68.9 23.6 64.1 26.0 59.4 28.4 - -
10
85.4 17.1 79.7 19.6 75.4 21.6 70.7 23.8 65.8 26.3 60.9 28.6 - -
11
87.6 17.2 81.7 19.8 77.3 21.8 72.5 24.1 67.5 26.5 62.5 28.9 - -
12
89.9 17.4 83.9 20.0 79.4 22.0 74.5 24.3 69.3 26.8 64.2 29.2 - -
80
5
85.0 19.4 79.4 22.3 75.1 24.5 70.4 27.1 65.5 29.8 60.7 32.5 55.8 35.2
6
87.4 19.5 81.6 22.5 77.1 24.8 72.4 27.3 67.4 30.1 62.4 32.8 57.3 35.5
7
89.9 19.7 84.0 22.7 79.4 25.0 74.5 27.6 69.3 30.4 64.2 33.2 59.0 35.9
8
92.5 20.0 86.3 23.0 81.6 25.3 76.6 27.9 71.3 30.8 66.0 33.5 - -
9
95.0 20.2 88.7 23.2 83.9 25.6 78.7 28.2 73.2 31.1 67.8 33.9 - -
10
97.6 20.4 91.1 23.4 86.1 25.8 80.8 28.5 75.2 31.4 69.6 34.2 - -
11
100 20.6 93.4 23.7 88.3 26.1 82.9 28.7 77.1 31.7 71.4 34.5 - -
12
103 20.8 95.9 23.9 90.7 26.3 85.1 29.0 79.2 32.0 73.4 34.9 - -
90
5
98.4 20.1 91.8 23.1 86.8 25.4 81.5 28.0 75.8 30.9 70.2 33.7 64.5 36.4
6
101 20.3 94.4 23.3 89.3 25.7 83.8 28.3 77.9 31.2 72.2 34.0 66.3 36.8
7
104 20.5 97.1 23.5 91.9 25.9 86.2 28.6 80.2 31.5 74.3 34.4 68.2 37.2
8
107 20.7 100 23.8 94.5 26.2 88.6 28.9 82.5 31.9 76.4 34.7 - -
9
110 20.9 103 24.0 97.1 26.5 91.1 29.2 84.7 32.2 78.5 35.1 - -
10
113 21.1 105 24.3 100 26.8 93.5 29.5 87.0 32.5 80.6 35.4 - -
11
116 21.3 108 24.5 102 27.0 95.9 29.8 89.2 32.8 82.6 35.8 - -
12
119 21.5 111 24.8 105 27.3 98.5 30.1 91.6 33.1 84.9 36.1 - -
100
5
110 23.9 102 27.5 96.9 30.3 91.0 33.4 84.6 36.9 78.4 40.2 72.0 43.4
6
113 24.2 105 27.8 100 30.6 93.5 33.8 87.0 37.2 80.5 40.6 74.0 43.9
7
116 24.4 108 28.1 103 30.9 96.2 34.1 89.5 37.6 82.9 41.0 76.1 44.3
8
119 24.7 111 28.4 105 31.3 98.9 34.5 92.0 38.0 85.2 41.4 - -
9
123 24.9 115 28.7 108 31.6 102 34.8 94.6 38.4 87.6 41.8 - -
10
126 25.2 118 29.0 111 31.9 104 35.2 97.1 38.8 89.9 42.3 - -
11
129 25.4 121 29.2 114 32.2 107 35.5 100 39.1 92.2 42.7 - -
12
133 25.7 124 29.5 117 32.5 110 35.9 102 39.5 94.7 43.1 - -
