Instructions on this documentation
This documentation is intended to help you safely work with the motor c ontroller CMMD-A S -C8-3A and
describes the functions, commissioning and error messages.
Target group
This documentation is intended exclusively for tec hnicians trained in control and automation techno-
logy, who have experience in installation, c ommissioning, programming and diagnostics of positioning
systems.
Versions
This documentation refers to the following versions:
– Motor controller CMMD-A S -C8-3A from Rev 02 ( Type plate).
Please note
Before using a newer firmware version, c hec k whether a newer version of the FCT plug-
in or user documentation is available for it ( www.festo.c om/sp).
servicing
Please consult your regional Festo contact if you have any technical problems.
Product identification
Rating plate CMMD-AS-C8-3A
Function
…
CMMD-AS-C8-3A
561406
CN98 P0021912
Rev 02
In: 1 k (95…250) V AC
(50…60) Hz 8 A
Out 1/2:
3 k (0…to Input Voltage) V AC
(0…1000) Hz 4 A
Type designation CMMD-AS-C8-3A
Part number e.g. 561406
Revision status e.g. Rev 02
Serial number e.g. CN98 P0021912
Input (In) 1-phase
95 … 250 V AC
50…60Hz,8A
Output 1, 2 (Out 1/2) 3-phase
0 … Input volta g e V AC
0 … 1000 Hz, 4 A
Tab. 1 Rating plate CMMD-AS-C8-3A (example)
Issue status of the specified standards
Standard: issue status
EN 60034-1:2010-10 EN 61800-3:2004-12 + A1:2012-03
EN 60204-1:2006/A1:2009-02 EN 61800-5-1:2007-09
Tab. 2 Issue statuses
