3Pin assignment
0
1
3
2
SAVE
POWER
24VDC
POWERV
ERRORV
RD
BA
RC
12
34
1 24 V operating voltage (electronics and inputs)
2 24 V load voltage (valves and outputs)
3 0 V
4 Earth connection
3.1 Meaning of the LED displays
Refer to manual CP fieldbus node 6".
