Festo CP−FB6−E 0802f English 21
OUT
1
Pin no. Designa
tion
Meaning
1
98
1
2
3
4
5
6
7
8
9
Sleeve
DO
/DO
DI
/DI
Earth
PE
+ 24 V
+ 0 V
RBST
Screen
Data out
Data out inverse
Data in
Data in inverse
Reference conductor
Protective earth for
remote bus
Remote bus supply
Remote bus supply
Make bridge to pin 5
Screening
*) Pins not listed must not be connected
